53

Setting Up AMD RAID Configuration

The BIOS CMOS Setup Utility screen appears.

Setting Up a bootable RAID Array

This section explains how to configure a bootable AMD RAID array.

Setting Up the BIOS

Figure 1.2 SATA Configuration Screen

Use the arrow keys to select the SATA Configuration (see Figure 1.2) and globally
set SATA Mode to RAID.

Start your computer, then press Delete to enter the BIOS setup.

Figure 1.1 BIOS CMOS Setup Utility Main Screen

1

3

Chapter 5

Setting Up AMD SB710 RAID Configuration

SATA Configuration

Serial-ATA Controller [Enhanced]

SATA Mode [IDE Mode]
SATA Master

Not Present

SATA Slave

Not Present

SATA Port1

Not Present

SATA Port2

Not Present

SATA Port3

Not Present

SATA Port4

ST32000641AS (2000.3G

SATA Port5

Not Present

SATA Port6

Not Present

Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.

Version 2.11.1210. Copyright (C) 2011, American Megatrends, Inc.

+/- : Change Opt.

lk

:Select Screen

F1:General Help

F2:Previous Values

F3:Optimized Defaults

F4:Save & Exit

mn

:Select Item

/Click

Enter / Dbl Click: Select

ESC/Right Click:Exit

Main

Advanced

Chipset M.I.B.III Boot Security Save & Exit

Select Advanced icon and press Enter (or double click it).

2

Serial-ATA Controller
