41
Using BIOS
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have
installed in your system.
M.I.B.III (MB Intelligent BIOS III) Menu
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Version 2.11.1210. Copyright (C) 2011, American Megatrends, Inc.
Processor Power Planes and
Voltage Controls
M.I.B. III ( MB Intelligent BIOS III)
Processor Power Planes and Voltage Controls
Memory Control [Auto]
HT Control
Auto Detect DIMM/PCI Clk [Enabled]
Clockgen Spread Spectrum [Enabled]
CPU/HT Reference Clock (MHZ) 200
CPU Unclock [Disabled]
CPU Voltage [Default]
VDDNB Voltage [Default]
NB Voltage [Default]
VDIMM Voltage [1.6V]
+/- : Change Opt.
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Enter/Dbl Click : Select
f
f
f
f Processor Power Planes and Voltage Controls
Scroll to this item and press to view the following screen.
Main Advanced Chipset M.I.B.III Boot Security Save & Exit
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Version 2.11.1210. Copyright (C) 2011, American Megatrends, Inc.
+/- : Change Opt.
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Enter/Dbl Click : Select
Core Clock multiplier
Processor Power Planes and Voltage Controls
Current CPU Speed: 3200MHz
Core Clock multiplier [Auto]
AltiveC3 Enable [Auto]
Slam Time Mode [Auto]
VSSlamTime [Auto]
Main Advanced Chipset M.I.B.III Boot Security Save & Exit
Current CPU Speed: 3200MHz
This item shows current CPU speed.
Core Clock multiplier (Auto)
Use this item to set the core clock multiplier.
AltiveC3 Enable (Auto)
This item allows users to select amdAltVidEn 0.24N:3x80[12]
Slam Time Mode (Auto)
This item allows users to set slam time mode, this option is only for RB-C3, BL-C3,
DA-C3.
VSSlam Time (Auto)
This item specifies the time to wait for voltage stabilization during altvid transitions
if a new VID is provided to the voltage regulator without ramping. 0:24N:3xDC
[31:29]
