31
Using BIOS
• CPU Temperature
• CPU FAN Speed
• SYS FAN Speed
• CPU Voltage
• DIMM Voltage
• NB Voltage
System Component Characteristics
These items display the monitoring of the overall inboard hardware health events,
such as CPU temperature, CPU & DIMM voltage, CPU & system fan speed... etc.
Press to return to the Advanced Menu page.
Press to return to the PC Health Status page.
This item allows you to enable/disable the control of the system fan speed by
changing the fan voltage.
SMART Fan Start PWM Value (30)
This item is used to set the start PWM value of the smart fan.
SMART Fan Start PWM Temp (40)
This item specifies the range that controls CPU temperature and keeps it from
going so high or so low when smart fan works.
DeltaT (+3)
SMART Fan Slope PWM Value (7 PWM value/unite)
This item is used to set the Slope Select PWM of the smart fan.
CPU Fan Full Speed Offset (-) (72)
This item is used to set the CPU fan full speed offset value.
