Using BIOS

PC Health Status

On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.

Scroll to this item and press to view the following screen:

fSmart Fan Function

This item enables you to define the CPU temperature by smartly adjusting the CPU
Fan. When it is set at certain temperature, the CPU Fan PWM value will change
accordingly.

CPU Smart Fan Control (Enabled)

Smart Fan Mode (Normal)

This item allows you to select the fan mode (Normal, Quiet, Silent, or Manual) for a
better operation environment. If you choose Normal mode, the fan speed will be auto
adjusted depending on the CPU temperature. If you choose Quite mode, the fan speed
will be auto minimized for quiet environment. If you choose Silent mode, the fan
speed will be auto restricted to make system more quietly. If you choose Manual
mode, the fan speed will be adjust depending on users’ parameters.

CPU Smart Fan Control

[Enabled]

Smart Fan Mode

[Normal]

SMART Fan Start PWM Value 30
SMART Fan Start PWM TEMP 40
DeltaT +3
SMART Fan Slope PWM Value 7 PWM value / unite
CPU Fan Full Speed Offset (-) 72

Main

Advanced

Chipset M.I.B.III Boot Security Save & Exit

Smart Fan Function

CPU temperature(

: 67

CPU FAN Speed : N/A
System FAN Speed

: 4245 RPM

CPU Voltage

: +1.356 V

DIMM Voltage

: +1.596 V

NB Voltage

: +1.212 V

Main

Advanced

Chipset M.I.B.III Boot Security Save & Exit

+/- : Change Opt.

: Select Screen

/Click: Select Item

F1: General Help

F2: Previous Values

F3: Optimized Defaults

F4: Save & Exit

ESC/Right Click: Exit

Enter/Dbl Click : Select
