6
Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
1. CPU Socket Socket AM3
+
for AMD AM3
+
FX TM /Phenom TM
II /Athlon TM II/Sempron TM 100 Series processors
2. CPU_FAN CPU cooling fan connector
3. DDR3_1~2 240-pin DDR3 SDRAM slots
4. ATX_POWER Standard 24-pin ATX power connector
5. IDE Primary IDE connector
6. SYS_FAN System cooling fan connector
7. SPK Speaker header
8. SATA1~6 Serial ATA connectors
9. F_PANEL Front panel switch/LED header
10. CLR_CMOS Clear CMOS jumper
11. SPI_DEBUG SPI_debug header for factory use only
12. LPT Parallel port header
13. F_USB1~2 Front Panel USB headers
14. SPDIFO SPDIF out header
15. CD_IN Analog audio input header
16. F_AUDIO Front panel audio header
17. PCI1~2 32-bit add-on card slots
18. CASE Chassis detect jumper
19. PCIEX1 PCI Express x1 slot
20. PCIEX16 PCI Express x16 slot for graphics interface
21. ATX12V 8-pin +12V power connector
