ONLY LICENSED PROFESSIONALS SHOULD INSTALL THIS PRODUCT
This product is patent protected by U.S. Patent numbers D553475, D554475 and 7390964.
RoHS Compliant.
Instruction / Installation Sheet
Recessed Low Voltage Media Plate
with 20 Amp Duplex Receptacle
Part # 45-0032-WH CONTINUED
Page 3 of 3 11/15/13
888.223.7977
770.662.8205
www.DataCommElectronics.com
ETL LISTED
CONFORMS TO
UL STD 514C
7-1/4”
TEMPLATE
45-0032-WH Recessed Low Voltage
Media Plate with Duplex 20 Amp Receptacle
ACTUAL SIZE
CUT ALONG DOTTED LINE 
7-1/8
”
