Environmental requirements
The following table lists the acceptable environmental ranges for both operating and nonoperating (such
as during transportation or storage) conditions.
Environmental requirements TABLE 8
Condition Acceptable during operation Acceptable during nonoperation
Ambient Temperature 0º to 40ºC (32º to 104ºF) -25º to 70ºC (-13º to 158ºF)
Humidity 10% to 85% RH non-condensing, at 40ºC (104ºF) 10% to 90% RH non-condensing, at
70ºC (158ºF)
Altitude 0 to 3 km (9,842 feet) above sea level 0 to 12 km (39,370 feet) above sea level
Shock 20 G, 6 ms, half-sine wave 33 G, 11 ms, half-sine wave, 3/eg Axis
Vibration 0.5 G sine, 0.4 gms random, 5-500 Hz 2.0 G sine, 1.1 gms random, 5-500 Hz
Airflow Two power supply and fan units
• Maximum - 35.70 cmh (21 cfm)
• Nominal - 16.99 cmh (10 cfm)
One power supply and fan unit
• Maximum - not available
• Nominal - not available
NOTE: Airflow is port side exhaust.
N/A
Heat dissipation 338 BTU/hr (24 port configuration) N/A
General specifications
The following table lists the general specifications for the Brocade 6505.
General specifications TABLE 9
Specification Description
Configurable port types F_Port, E_Port, M_Port, EX_Port, D_Port
System architecture Nonblocking shared-memory switch
System processor PowerPC 440EPx @ 667 MHz
ANSI Fibre Channel protocol FC-PH ( Fibre Channel Physical and Signalling Interface standard)
