Fixed Rack Mount Kit Installation Procedure

53-1001274-06

Installation procedure

ATTENTION

The switch must be turned off and disconnected from the fabric during this procedure.

NOTE

Although this document describes how to install single-height (1U) and double-height (2U) switches, the illustrations
show a single-height switch as a typical installation.

Complete these tasks to install the switch in a four-post rack:

“Attaching the front brackets”

“Installing the switch in the rack”

“Attaching the rear brackets to the front brackets”

“Attaching the rear brackets to the rack posts”
