FIT SYSTEM
62
FlaT PanEl MonITor SolUTIonS
Lots of choices for your flat panel monitor! Pick the features you need. note: all mounting options conform to VESa 75mm and 100mm mounting standards.
If you need a different standard or would like to discuss additional monitor solutions that are available, give us a call.
Flat Panel Monitor arm
• These steel arms have a vertical travel range of 16" and rotate 360°. Travel range depends on the size of your monitor.
• Mount with either a C-clamp to the edge of your workstation or drill through a shelf for added security. Clamp opens a maximum of 2"
and requires 3.5" of vertical clearance below the shelf.
• The Arms extend up to 22" from their mounting point.
• Ten-year warranty against manufacturing defects.
• The Standard and Super Arms are available in Black (BK) and Silver Metallic (SM). The Light Arm is available in Black (BK)
PRODUCT Supports Monitors Weighing Weight Part # Price
Single - Standard 7.5-25 lbs. 20 lbs. LCDzz $239*
Single - Super 13.5-44 lbs. 20 lbs. LCD2zz $289*
Single - Light 2-13.5 lbs. 20 lbs. 770BK $269.95*
Does not work with 24" or 30" wide Units.
QuickShip available for Standard and Super arms only.
Flat Panel Monitor Bar
• Add a row of flat panel monitors above your existing Unit by adding this Flat Panel Monitor Bar with a set of Extension Tubes and an
Additional Shelf (see Fit System: Accessories). Call for help with this configuration.
• Comes with one metal swivel-head Flat Panel Monitor Bracket. Add additional Brackets to support additional monitors. Each Bracket
holds up to 22 lbs. The amount of available swivel angle depends on the size of your monitor.
• At assembly, adjust your monitor to a comfortable depth. Install the Bar at any height in 1" increments. Install your monitor anywhere left
to right in 1" increments.
• Bars and Brackets are available in Black (BK) or Silver Metallic (SM).
PRODUCT Usable Mounting Width Weight Part # Price
48" wide 32" 18 lbs. 673zz $289.95
60" wide 44" 21 lb. 675zz $329.95
72" wide 56" 25 lbs. 677zz $339.95
Additional Flat Panel Monitor Bracket nA 2 lbs. 681zz $149.95
Does not work with Console Unit or Utility Unit.
Flat Panel Monitor Mount
• Secure your displays to your Fit System with these mounts. Choose the height, features, and capacity that fit your needs. All meet VESA
75mm and 100mm standards.
• The Single and Dual mounts use a 13" high stand and tilt-and-swivel knuckles to support your monitors. The Single (part #615zz)
supports a single display up to 22 lbs. The Dual (part #617zz) supports two displays up to 22 lbs. total and 17" across. The mount base
is 4.5"w x 4.5"d. Available in Black (BK) or Silver Metallic (SM)
• need a mount that’s a little taller? Choose the Extension Tube – Large 26" and add a knuckle to it. The Extension tube is a 2.5"-diameter
tube with a 4.5"-diameter base. The tube has holes every inch for installation of a tilt-and-swivel knuckle assembly.
• Install by drilling through the shelf and securing with four bolts. Drill required for installation.
• Available Silver Satin (SM).
PRODUCT
Supports Monitors Weighing Weight Part # Price
Single Monitor up to 22 lbs. 7 lbs. 615SM $219.95
Dual Monitor up to 22 lbs. 12 lbs. 617SM $319.95
Extension Tube – 26" 5 lbs. ZET26SS $99.95
Single Flat Panel Mount for Extension Tube - 26" 5 lbs. ZPMSSS $139.95
More Flat Panel choices
Don’t see what you’re looking for? We partner with selected vendors to provide you with even more choices. Give us a call and let us
know what you need. We’re sure to come up with the perfect fit – and ship it right to you!
SInglE MonITor
dUal MonITor
ExTEnSIon
TUBE - 26"
SInglE FlaT PanEl
MoUnT For
ExTEnSIon TUBE - 26"
jUST TakE oUr word For IT
Our carts are very strong — quite capable of holding a lot of
weight. But please put your equipment on it, not your friends.
Prices subject to change.
*Not available for discount.
