Anthro Fit Adjusta Unit Spec Guide - Manual (Page 2)

Quick Ship items usually ship
within 1-3 business days.
Fit
System
Metal Colors (zz)
Black (BK) Silver Metallic (SM)
Laminate Colors (xx)
Fog (FG) Bluestone (BS) Birch (BR) Black (BK)
color choIcES
Select your Fit System product colors from the
following swatches. Replace “zz” with a 2-letter
Metal Code and “xx” with a 2-letter Laminate Code.
57
conSolE UnIT
• Work standing or sitting at this wrap-around workstation.
• Comes with 2 shelves (1 manually positionable, 1 mechanically adjustable), 2 horizontal cable troughs (2.75"
wide x 24" long), 6 legs with holes in 1" increments for variable shelf height, 6 horizontal bottom cross tubes,
2 base tubes, 2 connector brackets, and 6 casters (3" size, front two locking).
• The large keyboard shelf raises and lowers from 7" above to 5.75" below the rear stationary surface with
an easy-to-manage spring-assisted mechanism and tilts 9° toward you for a positive tilt or 15° away for
a negative tilt.
• If you’d like the option of standing while you work, consider adding Extension Tubes and a Flat Panel
Monitor Arm (see Fit System: Accessories).
• Overall weight capacity of 150 lbs. The front keyboard shelf holds up to 40 lbs.
• Available in Black (BK) laminate.
PRODUCT Width (A) Width (B) Depth (C) Depth (D) Weight Part # Price
Console 72" 44.5" 22.5" 16.5" 138 lbs. FCCzz/BK3 $1,099
Does not accept Keyboard and Mouse Caddies, Keyboard Drawers, Corner Connector, Drawers,
or the CPU Slide-out.
UTIlITY UnIT
• Designed for tight spaces or small office equipment.
• Comes with 1 shelf, 2.75" wide horizontal cable trough, 4 legs with holes in 1" increments for variable shelf
height, 2 horizontal bottom cross tubes, 2 base tubes and 4 casters (3" size, front two locking). Integrated
cable management routes cords and cables to the side of the Unit.
• Overall weight capacity of 150 lbs.
PRODUCT Height Width (A) Width (B) Depth (C) Depth (D) Weight Part # Price
Utility 29" 30" 24.5" 22.25" 23.75" 50 lbs. FY3029zz/xx3 $409
Does not accept the Keyboard and Mouse Caddy-A, Corner Connector, Pencil Drawer, Large Drawer,
Keyboard Drawer, or Flat Panel Monitor Arm. Because the Utility Unit is so compact, use side-mounting
accessories with caution.
cornEr connEcTor
• Connect 2 or more Standard Units together to form an L-shaped or U-shaped space.
• Comes with 1 shelf, 1 leg and a 3" caster.
• Weight capacity of 100 lbs.
PRODUCT Depth (A) Depth (B) Width (C) Width (D) Height Weight Part # Price
Corner 26.5" 28" 38" 4.5" 29" 31 lb. 525zz/xx $269.95
Does not work with the Adjusta, Utility, or Console Units, and cannot be used with a single Unit. Please
specify if you plan to use the 5" Caster Retrofit or Glide Retrofit. The Glide Retrofit requires an adapter —
call for details.
Adjustable-height
Keyboard Shelf
12.75"
31"
16"
55.25"
59"
A
C
D
B
25"
76"
C
B
D
A
FY3629M/BK3 shown above.
D
B
28"
28"
C A
525SM/BS shown above.
anthro.com • 800.325.3841
