Anthro YES Cart Spec Guide - Manual (Page 4)

Quick Ship items usually ship
within 1-3 business days.
charging
carts
31 anthro.com • 800.325.3841
ColoR CHoICEs
Select your product colors from the following
swatches. Replace “zz” with a 2-letter Metal Code
and “xx” with a 2-letter Laminate Code. Metal Colors (zz)
Silver Metallic (SM) White (WH) Black (BK) Laguna Blue (BL) red Wagon (rd) Silver Satin (SS) Grey Metallic (GM) Polar White (PW)
CouNtERtoP CHARGING stAtIoN
by Belkin ®
• Charge 10 mobile devices – like a tablet, smartphone, or laptop – in this countertop charging station.
• Large bays measure 1.8"w x 7.25"d to hold devices with protective cases. Space-saving footprint measures 18"w x 14"d x 7"h.
• Concealed cable management organizes and protects cords underneath the tray and positions the connector right at the front of each bay.
• In back, ten power receptacles are spaced to fit most power adapters.
• Set the unit on a countertop, inside a cabinet, or on a cart. Use mounting holes in the base to bolt it into place.
• Comes with on/off power switch with indicator light, circuit breaker reset button, and surge protection
• Ships assembled. Freight included for continental US shipments. comes with one year warranty against manufacturing defects.
Product
Width Depth Height Weight Part # Price
Countertop Charging Station 18" 14" 7" 12 lbs. TABMD10 $209*
CHARGING CARts FoR suRFACE DEvICEs
CHARGING CARt FoR suRFACE
• Compact mobile cart stores, charges, and transports your Surface, Surface 2, and Surface RT devices.
• The 32-unit cart features wide bays to hold larger tablets and their cases. Bays are numbered and measure
1.25”w x 8.5”h x 10.5”d.
• Bay dividers have cable channels that position the power connector right next to the inlet on the device
for quick connection. Route cords through the cable channels at the top of the dividers, through the center
divider, and into the back locking it area.
• Open the back locking IT area and you'll see two power columns with electrical outlets, one on the left
and one on the right with 32 outlets total. A center divider separates the IT area from the User area with
pegboard holes for clips to organize your cords. three cord pass-through slots route cords from each shelf in
the user area back to the it area.
• The interface panel above the locking IT area has three convenient outlets to power your host computer and
peripherals. a two-position power switch with indicator light makes it easy to see from a distance when
power is on.
• The cart's small footprint (just 24"w x 24"d) makes it easy to tuck into corners and move through tight spaces.
• A dedicated storage area inside the front user area stores the teacher's laptop for quick access.
• Add storage for the headphones and other peripherals with the optional storage drawer (sold separately).
• Keyed locks with 2-point locking system protect each door. Lift and turn each latch to open doors. Add your
own padlock for more security.
• Four 4" casters go over rough surfaces and make the cart easy to more. All four casters lock.
• Ships assembled.
• Comes in Black (top surface, control panel, doors) with Silver Satin (side panels, base).
PRODUCT
Units Height Width Depth Weight Part # Price
Surface Charging Cart 32 46" 24.5" 23.75" 189 lbs. A320-05 $1,499
CHARGING CARt FoR suRFACE PRo
• Designed specifically for Microsoft Surface Pro, this 36-unit charging cart stores, charges, and transports any combination
of Surface Pro products safely and securely.
• The compact cart's small footprint measures just 29"w x 25"d to save space!
• Roomy bays measure 1.25"w x 14.25"d x 10"h, which is enough space for devices and cases.
• Two separate locking IT areas hold 18 cords and charge each, away from the front User area. Organize the
area the way you want it, then lock it away. Shelves and clips store power adapters and cable bundles, and
the power column has 36 outlets spaced to accept each device's plug.
• The power panel has four external power outlets, an on/off switch, and an indicator light that shows where the
power is directed in the cart—either to the left side, to the right side, or to the external outlets.
• A power management system alternates power from one side of the cart to the other to manage the cart's power
draw. this time cycle is set at 25 minutes when the cart leaves the factory, and can be adjusted anywhere from 15
minutes to 120 minutes using the time control located inside the it area.
• Doors (two on front and two on back) fold back flush against the side of the cart to save space.
• Four 4" locking casters move the cart where it's needed. 22" wide twin handles with round grips allow easy steering.
•
Keyed locks with 2-point locking system protect each door. Lift and turn each latch to open doors. Add your
own padlock for more security .
• Ships assembled.
• Comes in Black (top surface, control panel, doors) with Silver Satin (side panels, base).
PRODUCT Units Height Width Depth Weight Part # Price
Surface Pro Charging Cart 36 45.75" 33.25" 25" 238 lbs. A320-06 $2,199
baCk vieW baCk vieW
23.75
24.75
46
Cable ManageMenT
28.5 25.25
45.25
iT aRea
Belkin® is a registered trademark of Belkin International, Inc.
