Anthro YES Cart Spec Guide - Manual (Page 3)

charging
carts
CHARGING CARTS
30
Prices subject to change.
*Not available for discount.
YEs CARt FoR tABlEts WItH WIRED sYNC
• Sync, charge, store, and transport your tablets in this mobile cart with USB connection for 32 devices.
• Small footprint, just 24” square, tucks into any corner and rolls down narrow aisles with ease. At 46” high,
the cart is a comfortable teaching station, too.
• Adjustable shelves install at any height in 2/3” increments along the 31”-high installation track. Store devices on their
long side, in landscape orientation, or on their short side, in portrait orientation, as dictated by device size and the
position of the power inlet and on/off button. cart ships with shelves arranged for landscape storage.
• Adjustable bay dividers install at any width in 1/3” increments along each shelf's 12”-long installation track.
Supports devices of any thickness, with and without cases. Cart ships with bay dividers arranged for 1.25” wide bays.
• Locking IT area in back provides 32 USB ports for connecting your devices for wired syncing. Ports are numbered
to correspond to the bays up front. USB type B port on the interface panel connects to your host computer.
All USB ports are 2.1 amps and USB 2.0 standard. Each port comes with indicator lights to show port status.
Ports are visible through the back door so you can see status at a glance. USB ports provide simultaneous sync
and charge on devices that support that feature.
• Interface panel above the back door includes two outlets to power your peripherals, the USB type B connector
for your host computer, and the on/off switch.
• Power cord is 14 feet long to reach as far as you need. Cord is stored on strong cord hooks nested under the
handle so they’re safely out of the way and keep the cord convenient.
• Single front door opens 270 degrees so door lays flush against the side of the cart when open.
• Keyed locks front and back engage a two-point locking system for security. Padlock brackets position your
padlock to block access to the front and back latches for extra security.
• Four 4” casters, 2 total lock, 2 direction lock, move the cart where it’s needed, even over rough surfaces.
• Wide handle with 9.5” grip sits at a comfortable 40” height and makes the cart easy to steer.
• Top surface is made of contoured wood with strong vinyl thermoplastic laminate for smooth corners and soft edges.
• Bay dividers are made of molded ABS polymer so they don’t scratch your device. Cable channels along the
top of each route charging cords right to the front of the bay.
• Made with 14- and 16-gauge steel with durable baked-on powder coat finish.
• Ships assembled - just unpack and go! Empty cart weighs 149 lbs. Shipping weight is 169 lbs.
• Listed to UL standard 60950-1 in the US and Canada for both the enclosure and the electrical system, so you
know it’s safe.
Product Units Height (A) Width (B) Depth (C) Weight Part # Price
Tablet Sync 1-32 46.25" 23.75" 24.75" 169 lbs. YESTSYGMPW4 $2,479
oRIGINAl tABlEt CHARGING solutIoNs
tABlEt CHARGING CABINEt: BIG CAsE /stANDARD
• Secure, locking cabinet stores and charges up to 20 tablets and readers.
• Mount the cabinet to a wall, countertop, or shelf for extra security.
• Roomy bays hold common devices, with or without a case. The "Standard" cabinet has bays 7/8"w x 10.5"d x
8.5"h and holds 20 units. The "Big Case" cabinet has bays 1.25"w x 10.5"d x 8.5"h and holds 16 units. Each
storage bay is numbered so you can see at a glance which devices are docked and which are in use.
• dedicated storage cubby stores your laptop and connects the laptop to power.
• cable channels along the top of the bay dividers route the power connector cord to the front of the bay for
quick connection, and so you can see which devices are plugged in. Cable channels at the back of the cabinet
run cables from each bay to the side it area.
• Separate locking IT area on the side holds power adaptors. Cable management system organizes loose cables
cleanly. Power panel comes with 22 power receptacles — enough for all your devices plus a laptop and an
extra power receptacle. on/off power switch with indicator light shows you when the outlets have power.
Comes with 10 ft. power cord. Receptacle spacing in the IT area: 1-7/8" vertical spacing (from the top of one
receptacle to the top of the next), 2" horizontal spacing (from the left edge of one receptacle to the left
edge of the next).
• Keyed locks with two-point locking systems protect each door, front and back. Padlock brackets on the front
and back door latches hold your padlock for added security.
• Ships assembled with instructions and hardware to mount to studs and drywall (for wall-mounting).
cabinets have two pre-drilled holes for bolting to a countertop or shelf (for surface-mounting).
• Doors come in 3 colors: Polar White (PW), Laguna Blue (BL), or Red Wagon (RD). Top and bottom are Polar
White (PW) with Silver Satin (SS) accents. Top and bottom surfaces are 3/4"-thick wood.
Product Height (A) Width (B) Depth (C) Weight Part # Price
Big Case/ LagunaBlue 24" 21" 12" 65 lbs. TAB16SS-BL $739
Big Case/ Polar White 24" 21" 12" 65 lbs. TAB16SS/PW $739
Big Case/ Red Wagon 24" 21" 12" 65 lbs. TAB16SS-RD $739
Standard/ Laguna Blue 24" 21" 12" 65 lbs. TAB20SS-BL $749
Standard/ Polar White 24" 21" 12" 65 lbs. TAB20SS/PW $749
Standard/ Red Wagon 24" 21" 12" 65 lbs. TAB20SS-RD $749
B
C
A
SepaRaTe iT aRea
available in ThRee ColoR CoMbinaTionS:
RepoSiTionable ShelveS
USER AREA IT AREA
ReMovable BAYS
C
B
A
