Users Manual
CONTROL MODE
Control Mode provides access to the Loudspeaker Ampli-
fier’s internal DSP and allows you to control its settings.
You can enter Control Mode by clicking on the Control
button at the top of the main workspace, or from within any
loudspeaker’s Properties window. Any or all of the Control
functions can be restricted to authorized operators who
have password access; more information on password
authorization can be found in the Supervise Mode section
of this manual.
When you enter Control mode in the main workspace, the
directory tree on the left remains the same.
However, notice that the icons themselves have changed.
The CobraNet Rx and Tx arrows are gone. On the left side
Wink and Power buttons have been added. On the right
side, a Mute button is labeled with a driver symbol. Below it
is a Signal Present indicator.
Double-click an array icon to open its Properties window in Control mode. Notice that the left hand section of the Control Mode Proper-
ties window is the same as in Connect mode.
Turns “Wink” Light ON & OFF
Status Indicator
Name
Mute Button
Signal Present indicator
Toggles Power from On
to Standby
20
CONTROL
