6 TECHNICAL SPECIFICATION
Electrical
Volts/Ph/Frequency 230/1/50
Power consumed 500 Watts
Full load current 2.2 Amps
Rating Continuous
Max. No Starts per hour 60
Enclosure IPX4
Fuse Size 5 Amps
Mechanical
Max flow 12 litres/min
Max head (closed valve) 32 metres
Max working pressure * 600 kPa (6 bar)
Max liquid temperature 35 o C
Min liquid temperature 4 o C
Max ambient air temperature 40 o C
Max noise level 65 dB
P
ump
Dimensions
Length 210 mm
Width 130 mm
Height 231 mm
Weight 5.2 Kg
Connections
Inlet / outlet G ¾ Male
Connecting cable 1.5 metres
Materials
Body Brass
Shaft Stainless Steel
Mechanical Seal Nitrile/carbon/ceramic
Pump Parts Brass
*Max working pressure is the maximum pressure that can be applied to the pump
internal casing under any installation condition.
Stuart Turner reserve the right to amend the specification in line with its policy of
continuous development of its products.
