- 14 -

Cont ...

7 TECHNICAL

SPECIFICATION

Stuart Turner reserve the right to amend the specification in line with its policy of
continuous development of its products.

*Note: Max working pressure is the maximum pressure that can be applied to

the pump internal casing under any installation conditions.

7.11

Noise: The equivalent continuous A-weighted sound pressure level at a distance

of 1 metre from the pump does not exceed 70 dB(A).

Model

2.6 bar PS

3.6 bar PS

Electrical

Power supply
Volts/phase frequency

230/1/50

230/1/50

Enclosure

IPX5

IPX5

Type of motor

Induction

Induction

Power consumption

775 Watts

1136 Watts

Full load current

3.5 Amps

5.1 Amps

Rating

Continuous (S1)

Continuous (S1)

Max. No Starts per hour

60

60

Mechanical

Min inlet head

1 metres

1 metres

Max inlet head

10 metres

10 metres

Max head (closed valve)

26 metres

36 metres

Max working pressure*

600 kPa (6.0 bar)

900 kPa (9.0 bar)

Max ambient air temperature

40

o

C

40

o

C

Max water temperature

35

o

C

35

o

C

Min water temperature

4

o

C

4

o

C

Cut out flow

1 l/min (approx)

1 l/min (approx)

Cut in pressure

180 kPa (1.8 bar)

180 kPa (1.8 bar)

Vessel charge

210 kPa (2.1 bar)

210 kPa (2.1 bar)

P

ump

Dimensions

Length (max)

541 mm

541 mm

Width (max)

300 mm

300 mm

Height (excluding flexible hoses)

633 mm

633 mm

Gross Weight (including accessories)

17 Kg

18.5 Kg

Pump Connections: Inlet

G 1 Male

G 1 Male

Outlet

G 1 Male

G 1 Male
