- 7 -
Cont ...
2.28 Hot water supply: The pump must be supplied with a dedicated feed direct
from the hot water cylinder or storage tank which should be via a secondary
dedicated tapping (see Fig. 5).
Do not connect to the mains.
2 LOCATION - HOT WATER INSTALLATION
Fig. 4
Fig. 5
Factory installed
secondary tapping with
28 mm pipework to
pump.
Static inlet pressure 10
metres max
1
metre min
preferred area
Outlet head must be
below bottom of cold
water tank and able
to pass a minimum of
1 l/min of gravity flow
