background image

- 19 -

7 TECHNICAL

SPECIFICATION

Stuart Turner reserve the right to amend the specification in line with its policy of
continuous development of its products.

Note: For information on other voltages/frequencies which are not shown, consult any

supplementary instruction sheet supplied, or the rating label attached to the

pump.
*Note: Max working pressure is the maximum pressure that can be applied to the

pump internal casing under any installation conditions.

**Note: In normal circumstances the temperature of stored water should never exceed

65°C. A stored water temperature of 60°C is considered sufficient to meet all

normal requirements and will minimize deposition of scale in hard water areas.

Maximum permissible water temperature 65°C.

7.11

Noise: The equivalent continuous A-weighted sound pressure level at a distance

of 1 metre from the pump does not exceed 70 dB(A).

Model

U2.0 Single

U3.0 Single

U4.5 Single

Electrical

Power supply
Volts/phase freqency

230/1/50

230/1/50

230/1/50

Enclosure

IPX4

IPX4

IPX4

Type of motor

Induction

Induction

Induction

Power consumption

250 Watts

390 Watts

555 Watts

Full load current

1.1 Amps

1.7 Amps

2.5 Amps

Rating

Continuous (S1) @
9 l/min & above

Continuous (S1) @
9 l/min & above

Continuous (S1) @
9 l/min & above

Max. No Starts per hour

60

60

60

Mechanical

Max inlet head

8 metres

12 metres

12 metres

Max head (closed valve)

20 metres

32 metres

44 metres

Max working pressure*

600 kPa (6.0 bar)

600 kPa (6.0 bar)

600 kPa (6.0 bar)

Max ambient air temperature

40

o

C

40

o

C

40

o

C

Pressure vessel air pre-charge

90 kPa (0.9 bar)
(13 psi)

130 kPa (1.3 bar)
(18.5 psi)

130 kPa (1.3 bar)
(18.5 psi)

Max water temperature**

65

o

C

65

o

C

65

o

C

Min water temperature

4

o

C

4

o

C

4

o

C

Dimensions

Length

200 mm

200 mm

200 mm

Width

162 mm

162 mm

162 mm

Height (excluding flexible hoses)

243 mm

243 mm

243 mm

Gross Weight (packed)

7.8 Kg

7.8 Kg

8.4 Kg
