Component description – MAHLE RTI BFX-1 User Manual
Page 3
IMPORTANT:
Test drive vehicle after service to verify proper
brake system performance.
Page 2
Control Panel
(4) Bleeder Hoses
Fill Hose
Vacuum Hose
Hose Storage
Access Door
New Tank
New Tank
Float
Used Tank
(Accessed through rear)
UsedTank
Float
Fill Gun
Parking Stud
Component Description
Unpack all components and verify quantities per this illustration and adapter list on page 6.
Contact RTI if any items are missing.
