32
ARRANGEMENTS “K” with DX Cooling Coil ARRANGEMENT “K” with DX Cooling Coil
Unit Without Outside Air Hood With Outside Air Hood
Type, Center of Gravity Corner Weights (lbs) Center of Gravity Corner Weights (lbs)
Capacity Width Length X-Coor Y-Coor Corner #1 Corner #2 Corner #3 Corner #4 X-Coor Y-Coor Corner #1 Corner #2 Corner #3 Corner #4
RT10 32.75 134 73.1 15.7 217 260 240 200 69.2 15.7 241 257 238 223
PV10 32.75 134 73.0 15.7 217 259 239 200 69.1 15.7 241 257 238 223
RT15 32.75 134 74.5 15.8 217 272 254 203 70.6 15.9 241 269 252 226
PV15 32.75 134 74.3 15.8 217 269 252 203 70.4 15.8 241 267 250 226
RT20 43.75 134 75.0 21.0 249 317 292 230 71.0 21.0 278 313 290 258
PV20 43.75 134 74.4 21.0 249 311 287 229 70.4 21.0 278 308 284 257
RT25 43.75 134 76.0 21.0 256 335 310 237 72.1 21.1 285 332 308 265
PV25 43.75 134 75.5 21.0 255 329 305 236 71.6 21.1 284 326 303 264
RT30 54.75 134 74.6 26.1 331 417 380 302 71.1 26.2 365 412 377 334
PV30 54.75 134 73.9 26.1 330 407 370 301 70.4 26.1 364 402 368 333
RT35 54.75 134 77.0 25.8 306 413 369 273 73.2 25.9 340 409 367 304
PV35 54.75 134 76.3 25.8 305 403 359 272 72.4 25.9 339 399 357 303
RT40 60.25 134 77.2 28.6 320 436 393 289 73.4 28.6 356 431 391 323
PV40 60.25 134 76.6 28.6 319 426 383 288 72.7 28.6 355 421 381 322
RT50 43.75 160 91.1 21.0 338 447 414 313 87.7 21.1 366 444 412 340
PV50 43.75 160 90.4 21.0 336 436 403 311 86.9 21.1 364 433 402 338
RT60 54.75 160 91.3 25.9 392 521 469 352 87.9 26.0 425 517 467 383
PV60 54.75 160 90.3 25.9 388 503 451 348 86.7 25.9 422 499 449 380
RT70 54.75 160 92.2 25.7 405 551 488 359 88.8 25.8 438 547 487 390
PV70 54.75 160 91.2 25.7 402 532 470 355 87.8 25.7 435 528 469 386
RT80 60.25 160 92.8 28.5 424 586 526 381 89.4 28.6 459 582 524 414
PV80 60.25 160 91.9 28.5 421 567 508 377 88.4 28.5 456 563 506 410
ARRANGEMENTS “L” with Chilled Water Coil ARRANGEMENT “L” with Chilled Water Coil
Unit Without Outside Air Hood With Outside Air Hood
Type, Center of Gravity Corner Weights (lbs) Center of Gravity Corner Weights (lbs)
Capacity Width Length X-Coor Y-Coor Corner #1 Corner #2 Corner #3 Corner #4 X-Coor Y-Coor Corner #1 Corner #2 Corner #3 Corner #4
RT10 32.75 160 74.6 15.8 314 274 257 294 71.3 15.9 337 272 255 317
PV10 32.75 160 74.5 15.8 314 273 256 294 71.3 15.9 337 271 255 317
RT15 32.75 160 77.8 15.9 307 291 276 291 74.6 15.9 331 289 274 314
PV15 32.75 160 77.7 15.9 307 289 274 291 74.4 15.9 331 287 273 314
RT20 43.75 160 78.6 21.1 348 337 315 326 75.2 21.2 377 334 313 353
PV20 43.75 160 78.2 21.1 347 332 310 324 74.8 21.2 375 329 309 352
RT25 43.75 160 79.2 21.2 359 351 330 337 75.8 21.2 387 348 328 364
PV25 43.75 160 78.8 21.2 357 346 325 335 75.4 21.2 385 344 323 362
RT30 54.75 160 80.4 26.2 408 412 379 375 77.0 26.3 440 408 377 406
PV30 54.75 160 79.8 26.2 405 403 371 372 76.4 26.3 438 400 369 403
RT35 54.75 160 80.2 26.1 422 424 385 384 76.8 26.1 455 421 383 415
PV35 54.75 160 79.6 26.0 420 416 377 381 76.2 26.1 453 412 375 412
RT40 60.25 160 80.5 28.8 441 446 409 404 77.1 28.9 476 443 407 438
PV40 60.25 160 80.0 28.8 438 438 401 402 76.5 28.9 474 434 399 435
RT50 43.75 186 93.8 21.2 450 458 428 421 90.7 21.2 478 455 427 448
PV50 43.75 186 93.2 21.1 447 448 419 418 90.1 21.2 475 446 418 445
RT60 54.75 186 94.9 26.1 512 533 486 467 91.8 26.2 544 530 485 498
PV60 54.75 186 94.1 26.1 506 518 471 460 90.9 26.1 538 514 469 491
RT70 54.75 186 94.9 25.9 532 555 499 479 91.9 26.0 565 552 498 510
PV70 54.75 186 94.1 25.9 527 539 484 473 91.0 25.9 559 536 483 504
RT80 60.25 186 95.5 28.9 554 585 539 510 92.4 28.9 588 581 537 543
PV80 60.25 186 94.8 28.9 548 569 523 504 91.6 28.9 583 566 522 537
ARRANGEMENTS “L” with DX Cooling Coil ARRANGEMENT “L” with DX Cooling Coil
Unit Without Outside Air Hood With Outside Air Hood
Type, Center of Gravity Corner Weights (lbs) Center of Gravity Corner Weights (lbs)
Capacity Width Length X-Coor Y-Coor Corner #1 Corner #2 Corner #3 Corner #4 X-Coor Y-Coor Corner #1 Corner #2 Corner #3 Corner #4
RT10 32.75 160 77.7 15.8 273 258 240 254 74.0 15.8 297 256 239 277
PV10 32.75 160 77.7 15.8 273 257 240 254 74.0 15.8 297 255 238 277
RT15 32.75 160 81.3 15.9 267 276 260 251 77.5 15.9 291 273 258 274
PV15 32.75 160 81.1 15.9 266 274 258 251 77.3 15.9 290 271 256 274
RT20 43.75 160 81.7 21.1 308 321 298 286 77.8 21.1 336 318 297 313
PV20 43.75 160 81.3 21.1 306 316 294 284 77.4 21.1 335 313 292 312
RT25 43.75 160 82.2 21.1 318 335 313 297 78.4 21.2 346 333 311 324
PV25 43.75 160 81.8 21.1 316 331 308 295 78.0 21.1 345 328 307 322
RT30 54.75 160 83.1 26.1 367 396 362 335 79.3 26.2 400 393 360 366
PV30 54.75 160 82.5 26.1 364 388 354 332 78.7 26.2 397 384 352 364
RT35 54.75 160 82.8 26.0 381 409 368 344 79.1 26.0 414 405 367 375
PV35 54.75 160 82.2 25.9 379 400 360 341 78.5 26.0 412 397 359 372
RT40 60.25 160 83.0 28.7 400 431 392 365 79.2 28.8 435 427 390 398
PV40 60.25 160 82.4 28.7 398 422 384 362 78.7 28.8 433 419 382 395
RT50 43.75 186 97.1 21.1 407 444 414 379 93.7 21.1 435 442 413 406
PV50 43.75 186 96.5 21.1 403 435 405 376 93.1 21.1 431 433 404 403
RT60 54.75 186 97.9 26.0 468 520 472 425 94.5 26.1 501 517 470 456
PV60 54.75 186 97.0 26.0 462 504 456 418 93.6 26.1 495 501 455 449
RT70 54.75 186 97.8 25.9 489 542 485 437 94.5 25.9 522 538 483 468
PV70 54.75 186 96.9 25.8 483 526 469 431 93.6 25.9 516 522 468 462
RT80 60.25 186 98.2 28.8 510 571 524 468 94.9 28.9 545 568 523 501
PV80 60.25 186 97.5 28.8 505 556 509 462 94.1 28.8 539 552 507 495
