Sterling RT - Manual (Page 31)

31
ARRANGEMENTS “G” ARRANGEMENT “G”
Unit Without Outside Air Hood With Outside Air Hood
Type, Center of Gravity Corner Weights (lbs) Center of Gravity Corner Weights (lbs)
Capacity Width Length X-Coor Y-Coor Corner #1 Corner #2 Corner #3 Corner #4 X-Coor Y-Coor Corner #1 Corner #2 Corner #3 Corner #4
RT20 43.75 108 60.0 20.7 223 279 252 201 56.3 20.8 253 275 249 229
PV20 43.75 108 59.6 20.7 223 274 246 200 55.8 20.8 252 269 244 228
RT25 43.75 108 61.0 20.8 230 298 270 208 57.3 20.8 259 293 267 236
PV25 43.75 108 60.5 20.8 229 292 264 207 56.9 20.8 259 288 262 235
RT30 54.75 108 62.1 25.4 267 361 313 232 58.4 25.5 302 355 310 264
PV30 54.75 108 61.5 25.4 266 351 304 230 57.7 25.5 301 346 301 262
RT35 54.75 108 61.5 25.1 284 375 318 240 58.0 25.2 319 369 315 272
PV35 54.75 108 60.9 25.1 283 365 308 239 57.3 25.2 318 359 306 271
RT40 60.25 108 61.7 27.9 297 395 341 256 58.1 28.0 334 389 338 290
PV40 60.25 108 61.1 27.9 295 385 332 255 57.5 28.0 333 379 329 289
RT50 43.75 134 75.6 20.9 303 392 360 278 72.3 21.0 332 389 358 305
PV50 43.75 134 75.0 20.9 301 382 350 275 71.6 20.9 330 378 348 303
RT60 54.75 134 76.3 25.7 352 465 413 313 72.9 25.8 386 461 411 344
PV60 54.75 134 75.4 25.7 348 448 396 308 72.0 25.8 382 443 394 340
RT70 54.75 134 76.1 25.5 372 489 427 325 72.9 25.6 406 484 425 356
PV70 54.75 134 75.2 25.5 368 471 410 320 72.0 25.6 402 466 408 352
RT80 60.25 134 76.2 28.3 393 518 460 349 73.0 28.4 430 514 458 383
PV80 60.25 134 75.4 28.3 389 500 443 344 72.1 28.3 426 496 441 378
RT12 60.25 160 90.4 28.6 492 640 577 444 87.5 28.6 527 636 575 477
PV12 60.25 160 89.5 28.5 485 615 553 435 86.5 28.6 520 611 551 469
ARRANGEMENTS “J” ARRANGEMENT “J”
Unit Without Outside Air Hood With Outside Air Hood
Type, Center of Gravity Corner Weights (lbs) Center of Gravity Corner Weights (lbs)
Capacity Width Length X-Coor Y-Coor Corner #1 Corner #2 Corner #3 Corner #4 X-Coor Y-Coor Corner #1 Corner #2 Corner #3 Corner #4
RT20 43.75 134 66.8 20.9 283 281 257 259 63.1 20.9 312 278 255 286
PV20 43.75 134 66.4 20.9 282 277 252 257 62.7 20.9 311 273 250 284
RT25 43.75 134 67.3 20.9 294 296 271 269 63.8 21.0 323 293 269 297
PV25 43.75 134 67.0 20.9 292 292 267 267 63.4 20.9 321 288 265 295
RT30 54.75 134 68.1 25.6 344 356 313 303 64.6 25.7 378 351 311 334
PV30 54.75 134 67.7 25.6 341 348 306 299 64.1 25.7 375 344 304 331
RT35 54.75 134 67.3 25.4 363 366 316 313 63.9 25.4 397 362 314 344
PV35 54.75 134 66.9 25.3 360 358 309 310 63.4 25.4 394 354 307 341
RT40 60.25 134 67.5 28.2 380 386 339 334 64.0 28.2 416 381 336 367
PV40 60.25 134 67.1 28.1 377 378 331 330 63.6 28.2 413 373 329 364
RT50 43.75 160 81.4 21.0 372 385 356 344 78.2 21.0 400 383 354 371
PV50 43.75 160 81.0 21.0 368 377 348 339 77.7 21.0 396 374 346 367
RT60 54.75 160 82.7 25.9 430 459 412 385 79.4 25.9 463 456 410 417
PV60 54.75 160 82.0 25.8 423 445 397 378 78.6 25.9 456 441 396 409
RT70 54.75 160 81.8 25.7 454 475 419 401 78.7 25.7 487 471 417 432
PV70 54.75 198 81.1 25.6 447 460 405 393 77.9 25.7 480 456 403 425
RT80 60.25 160 81.9 28.5 482 505 452 431 78.8 28.5 517 501 451 465
PV80 60.25 160 81.3 28.4 475 490 438 424 78.1 28.5 510 486 436 458
RT12 60.25 186 96.0 28.7 584 624 566 530 93.1 28.7 619 620 564 563
PV12 60.25 186 93.2 28.5 544 547 491 488 90.0 28.6 579 543 489 521
ARRANGEMENTS “K” with Chilled Water Coil ARRANGEMENT “K” with Chilled Water Coil
Unit Without Outside Air Hood With Outside Air Hood
Type, Center of Gravity Corner Weights (lbs) Center of Gravity Corner Weights (lbs)
Capacity Width Length X-Coor Y-Coor Corner #1 Corner #2 Corner #3 Corner #4 X-Coor Y-Coor Corner #1 Corner #2 Corner #3 Corner #4
RT10 32.75 134 70.1 15.8 254 279 260 237 66.7 15.8 278 276 258 260
PV10 32.75 134 70.0 15.8 254 278 259 237 66.7 15.8 278 276 257 260
RT15 32.75 134 71.4 15.9 254 291 274 240 68.1 15.9 279 288 272 263
PV15 32.75 134 71.2 15.9 254 288 271 239 67.8 15.9 278 286 270 263
RT20 43.75 134 72.2 21.1 287 336 312 267 68.7 21.1 316 332 310 295
PV20 43.75 134 71.7 21.1 287 330 306 266 68.2 21.1 315 327 304 294
RT25 43.75 134 73.2 21.1 293 354 330 274 69.8 21.1 322 351 328 301
PV25 43.75 134 72.8 21.1 293 348 324 273 69.3 21.1 322 345 322 301
RT30 54.75 134 74.6 26.1 331 417 380 302 71.1 26.2 365 412 377 334
PV30 54.75 134 73.9 26.1 330 407 370 301 70.4 26.1 364 402 368 333
RT35 54.75 134 74.6 25.9 344 432 389 309 71.2 26.0 378 428 386 341
PV35 54.75 134 73.9 25.9 343 422 379 308 70.5 26.0 377 418 377 340
RT40 60.25 134 74.9 28.7 358 454 413 326 71.4 28.8 394 450 410 360
PV40 60.25 134 74.3 28.7 357 444 403 324 70.8 28.7 393 440 401 358
RT50 43.75 160 87.9 21.1 379 462 431 353 84.8 21.1 407 459 429 380
PV50 43.75 160 87.2 21.1 377 452 420 351 84.1 21.1 405 449 418 378
RT60 54.75 160 88.6 26.0 433 536 486 392 85.4 26.1 466 533 484 423
PV60 54.75 160 87.5 26.0 430 518 468 388 84.2 26.0 463 514 466 419
RT70 54.75 160 89.5 25.8 446 566 505 398 86.4 25.9 479 562 504 429
PV70 54.75 160 88.5 25.8 443 548 488 394 85.3 25.8 476 544 486 426
RT80 60.25 160 90.2 28.6 465 601 543 420 87.0 28.6 500 597 541 454
PV80 60.25 160 89.2 28.6 462 582 525 416 86.0 28.6 479 578 523 450
