Sterling RT User Manual
Page 30
30
ARRANGEMENTS “B”
ARRANGEMENT “B”
Unit
Without Outside Air Hood
With Outside Air Hood
Type,
Center of Gravity Corner
Weights
(lbs) Center of Gravity Corner
Weights
(lbs)
Capacity
Width
Length
X-Coor Y-Coor Corner #1 Corner #2 Corner #3 Corner #4 X-Coor Y-Coor Corner #1 Corner #2 Corner #3 Corner #4
RT10
32.75
72
35.9
15.4
161 160 141 142
32.6
15.4
187 154 138 167
PV10
32.75
72
35.8
15.4
161 159 141 142
32.5
15.4
187 154 137 167
RT15
32.75
72
36.9
15.4
163 171 153 145
33.7
15.5
190 166 149 170
PV15
32.75
72
36.7
15.4
163 169 150 145
33.5
15.5
189 164 147 170
RT20
43.75
72
36.6
20.6
196 202 179 174
33.3
20.7
227 196 175 203
PV20
43.75
72
36.2
20.6
195 196 174 173
32.9
20.7
226 190 170 202
RT25
43.75
72
37.3
20.6
198 213 190 177
34.1
20.7
230 207 186 206
PV25
43.75
72
37.0
20.6
197 207 185 175
33.7
20.7
229 201 181 205
RT30
54.75
72
37.7
25.3
232 255 218 198
34.5
25.4
269 247 214 232
PV30
54.75
72
37.2
25.2
230 246 209 196
33.9
25.3
267 238 205 230
RT35
54.75
72
37.7
25.1
245 269 228 207
34.6
25.3
282 261 224 241
PV35
54.75
72
37.2
25.1
243 260 219 205
34.1
25.2
280 252 215 239
RT40
60.25
72
38.2
27.9
254 287 248 219
35.1
28.0
294 279 243 256
PV40
60.25
72
37.8
27.9
253 278 239 217
34.6
28.0
292 270 234 253
RT50
43.75
98
51.2
20.8
278 304 276 253
48.3
20.9
308 299 274 281
PV50
43.75
98
50.7
20.8
275 294 267 250
47.8
20.9
305 290 264 278
RT60
54.75
98
51.4
25.7
324 356 315 286
48.5
25.8
359 351 312 319
PV60
54.75
98
50.7
25.6
318 340 299 280
47.7
25.7
353 335 296 313
RT70
54.75
98
51.6
25.6
341 378 333 300
48.8
25.7
376 373 329 332
PV70
54.75
98
50.9
25.6
336 362 317 294
48.0
25.6
371 356 314 326
RT80
60.25
98
52.2
28.4
358 407 363 319
49.4
28.5
396 401 360 354
PV80
60.25
98
51.6
28.3
353 391 347 313
48.7
28.4
390 385 344 348
RT12
60.25 124
65.7
28.7
467 525 476 423
63.1
28.7
503 520 474 457
PV12
60.25 124
65.0
28.6
456 503 454 412
62.3
28.7
493 498 452 447
ARRANGEMENTS “C”
ARRANGEMENT “C”
Unit
Without Outside Air Hood
With Outside Air Hood
Type,
Center of Gravity Corner
Weights
(lbs) Center of Gravity Corner
Weights
(lbs)
Capacity
Width
Length
X-Coor Y-Coor Corner #1 Corner #2 Corner #3 Corner #4 X-Coor Y-Coor Corner #1 Corner #2 Corner #3 Corner #4
RT10
32.75
98
43.3
15.5
210 166 150 190
40.1
15.6
236 163 148 214
PV10
32.75
98
43.3
15.5
210 166 150 190
40.0
15.6
235 162 147 214
RT15
32.75
98
43.9
15.6
216 175 158 196
40.7
15.6
241 171 156 220
PV15
32.75
98
43.8
15.6
215 173 157 195
40.6
15.6
240 169 154 219
RT20
43.75
98
43.5
20.8
257 205 185 233
40.3
20.8
287 200 182 261
PV20
43.75
98
43.2
20.8
255 201 181 230
40.0
20.8
285 196 178 259
RT25
43.75
98
43.8
20.8
263 212 192 238
40.7
20.9
293 208 189 267
PV25
43.75
98
43.6
20.8
260 208 189 236
40.5
20.9
290 204 186 264
RT30
54.75
98
44.1
25.5
308 251 220 269
41.0
25.6
343 246 217 302
PV30
54.75
98
43.8
25.5
304 245 213 265
40.6
25.6
339 239 210 297
RT35
54.75
98
43.8
25.4
324 261 226 281
40.8
25.5
359 256 223 313
PV35
54.75
98
43.5
25.4
320 255 220 276
40.4
25.5
355 249 217 309
RT40
60.25
98
44.0
28.2
340 277 244 299
41.0
28.3
378 271 240 334
PV40
60.25
98
43.7
28.2
336 271 237 295
40.7
28.3
374 265 234 330
RT50
43.75 124
57.3
20.9
346 296 272 317
54.4
21.0
375 293 270 345
PV50
43.75 124
57.0
20.9
340 289 265 312
54.1
21.0
369 285 263 340
RT60
54.75 124
57.4
25.9
402 346 310 360
54.5
25.9
436 342 307 392
PV60
54.75 124
57.0
25.8
393 334 298 350
54.0
25.9
427 329 295 382
RT70
54.75 124
57.3
25.8
428 368 327 381
54.6
25.9
462 363 325 413
PV70
54.75 124
56.8
25.7
420 355 315 372
54.1
25.8
454 350 312 404
RT80
60.25 124
57.6
28.6
449 389 350 404
54.8
28.6
485 384 347 438
PV80
60.25 124
56.8
28.5
442 373 335 397
54.0
28.6
478 369 333 431
RT12
60.25 150
70.8
28.8
559 500 456 510
68.2
28.8
594 469 454 544
PV12
60.25 150
70.3
28.7
545 481 438 496
67.7
28.8
580 477 436 530
XII. CENTER OF GRAVITY
RT = NATURAL VENT PV = POWER VENT
Values Based on Average Motor Weight
(Actual Center of Gravity and Corner Weights For Specifi c Motor Size are Available Upon Request)
Figure 16
