Product development is a continuous policy of Yokogawa and therefore specifications may be subject to change without

notice
The following generic specifications apply however; please check exact features and model number with serial numbers

on the units provided.

2. GENERIC SPECIFICATIONS

A) Process Connection:

Process flange ratings are ASME B16.6-1996

B) Sample Outlet Connection:

Standard 3/8” o.d. Sawgelock

stainless steel

Flow Rate: Typically 3 Lts./min conditioned at 15°C or

4 Lts./min conditioned at 20°C, pending application
Pressure: ΔP across ARS, < 1psi

NOTE

The sample transport line should be heat traced and

insulated to prevent subsequent sample condensation.

C) Mounting:

Vertical on top of customer supplied process isolation

valve for horizontal process line.

NOTE

If mounting on vertical process line, install appropriate

elbow or Y-piece prior to process isolation valve to

ensure ARS mounted in vertical position – Refer to

Installation details.

D) Instrument Air Connection:

Standard 1/2” o.d. Sawgelock

, stainless steel

Supply Pressure: 60-110 psig (~ 54-7.5 Bar)
Flow Rate: Dual 10 SCFM Vortex Tubes: Standard

Dual 15 SCFM Vortex Tubes: Optional

Grade: Clean, Dry, Oil Free and <5μ particles with

–40

C dew point and ISA grade HC free

E) Steam Supplement Connection:

Filter Section

Standard ¼” o.d. Sawgelock

, stainless steel

Pressure: 50-150 psig
Temperature: maximum 238oC

F) Materials of Construction:

Lower filter section: 316 stainless steel
Lower filter mesh: 316 stainless steel knitted, 0.011”

diameter wire
Inlet temperature section: 316 stainless steel
Heat Exchanger: 316 stainless steel

G) Electrical Power supply:

Not Required

H) Self Acting Controller:

Adjustable set-point indicating dial
316 Stainless steel sample wetted parts
Brass body air control valve, high CV
Highly reliable with practically no moving parts

I) Shipping Details

Size: Approximately 56 in (1422 mm) H x 24 in (609

mm) W x 12 in (304 mm)D
Weight: Approximately 110 lbs (49.8 kg) without

optional equipment
