IM 60A02S01-01E-A
OPTIONAL SPECIFICATIONS (For Explosion Protected Type)
OPTIONAL SPECIFICATIONS
Note 1: Option only available with /FF1 Option.
ORDERING INFORMATION
Specify the following when ordering:
1. Model and suffix codes.
2. Option codes.
3. Tag number
4. Calibration range desired (optional)
OPTIONS
The MLX is fully field configurable from the front panel. To order a
pre-configured unit, specify the /ENG option followed by the desired
setpoints (zero, full scale, and engineering units).
Item
Description
Code
Canadian Standards
Association (CSA)
Canadian Standards
Association (CSA)
CSA Intrinsically Safe/CSA Explosionproof/ CSA Dust-Ignition-Proof /CSA Non-incendive Approval
Certified to: CSA C22.2 No. 25, CSA C22.2 No. 30, CSA C22.2 No. 157, CSA C22.2 No. 213,
CSA C22.2 No. 60079-0, CAN/CSA E60079-11
Explosionproof/Dust-Ignition-Proof for:
Class I, II, III; Groups A - G; Divisions 1 & 2.
Class I, Zone 1, Group IIC T4.
Tamb. –40°C to 80°C
Intrinsically Safe for:
Class I, Division 1, II, III; Groups A - G; Divisions 1 & 2.
Zone 20, Class I, Zone 0
AEx ia IIC T4
Tamb. –40°C to 80°C
Entity parameters: Ui=24 V, Ii=150 mA, Pi=0.65 W, Ci=0 nF, Li=0 H
Non-Incendive for:
Class I, II, III; Groups A - D, F, G; Divisions 2.
Class I, Zone 2, Group IIC T4.
Tamb. –40°C to 80°C
Enclosure rating: "Type 4X."
Temperature Class: T4
Ambient Temperature: –40°C to 80°C
CU1
IECEx Scheme
IEC Intrinsically Safe/IEC Flameproof/IEC Non-Incendive Approval
Applicable Standard: IEC 60079-0:2011, IEC 60079-1:2008, IEC 60079-11:2011,
IEC 60079-26:2009, IEC 60079-31:2008
Explosionproof/Dust-Ignition-Proof for:
Ex d IIC T4 Gb
Ex tb IIC T135 Db
Intrinsically Safe for:
Ex ia IIC T4 Ga
Entity parameters: Ui=24 V, Ii=150 mA, Pi=0.65 W, Ci=0 nF, Li=0 H
Non-Incendive for:
Ex nA IIC T4 Gc
Ambient Temperature: –40°C to 80°C
Enclosure: IP66 and IP67
SU2
Combination of
Approvals
Combination of FU1, CU1 and KU21 Approvals
V1U
INMETRO (Brazil)
Certificate
INMETRO Intrinsically Safe/INMETRO Flameproof Approval (Pending)
BU1
GOST (Russian)
Certificate
Russian GOST certifícate (Pending)
QR1
Item
Description
Code
Coating
Epoxy resin coating
Polyurethane-Epoxy Anti-corrosion coating
Note 1
X1
X2
Note 1
Calibration
Calibration range and scale
ENG
Stainless steel tag
plate
Stainless steel tag screw attached to housing
Stainless steel tag wired to housing
SST
SSW
Paint
Light Blue (RAL # 5012)
Orange (RAL # 2008)
Red (
Munsell # 7.5 R4/14
)
Mint Green
Silver (RAL # 9006)
Yellow (RAL # 1018)
Gray (RAL # 7046)
P1
P2
P3
P4
P5
P6
P7
