ENGLISH
ENGLISH
22
23
CAUTION: Maintenance
DISASSEMBLY
1. Replacement parts may be available at the store where you purchased
your faucet.
2. When replacement parts are not available, please write or call Price
Pfister Consumer Service.
3. Always turn off water and relieve pressure before working on your
faucet.
NOTE: Trim Care
Cleaning Instructions:
For all Handles and decorative finishes, use only a soft damp
cloth to clean and shine. Use of polish, detergents, abrasive
cleaners, organic solvents or acid may cause damage. Use of
other than a soft damp cloth will nullify our warranty!
Special Trim:
Trim products which contain Porcelain or other similar
substance are not acceptable for public areas or Commercial
use. Installation of Said Trim is at Users Risk!
1–800–PFAUCET (1–800–732–8238)
For Toll-Free Pfaucet information call
1–800–PFAUCET (1–800–732–8238)
or visit www.pricepfister.com
• Installation Support
• Care and Warranty Information
22 AERATOR CLEANING
Over time, the aerator in your faucet may become clogged with debris. To clean the
aerator, unscrew Aerator Housing (22A) from Spray Head (22B) by using Removal Tool
(22C). Remove Aerator Seal (22D) and Aerator Cartridge (22E) from Aerator Housing
(22A). Clean Aerator Cartridge (22E) and Aerator Housing (22A).
23 HANDLE REMOVAL AND CARTIDGE REPLACEMENT
Turn off water supplies and relieve pressure before working on your faucet. Carefully
pry off Handle Button (23A). Using a small Flat Head Screwdriver, loosen Set Screw
(23B) and remove Handle (23C). Remove the Dome Cap (23D) by unscrewing
counterclockwise. Using pliers, unscrew the retainer ring (23E). Carefully remove the
Cartridge (23F) by pulling it straight out. Reassemble valve by reversing steps.
6
22A
23B
23C
23D 23E
23F
23A
22D
22E
22C
22B
