7
1
2
CAUTION: Maintenance
DISASSEMBLY
1. Replacement parts may be available at the store where
you purchased your faucet.
2. When replacement parts are not available, please write or
call Price Pfister Consumer Service.
3. Always turn off water and relieve pressure before
working on your faucet.
NOTE: Trim Care
Cleaning Instructions:
For all Handles and decorative finishes, use only a soft damp
cloth to clean and shine. Use of polish, detergents, abrasive
cleaners, organic solvents or acid may cause damage. Use
of other than a soft damp cloth will nullify our warranty!
Special Trim:
Trim products which contain Porcelain or other similar
substance are not acceptable for public areas or Commercial
use. Installation of Said Trim is at Users Risk!
14 SPOUT INSTALLATION (Fig.M)
Screw Spout (1) to Pipe Nipple (2) and tighten until Spout
(1) is properly positioned to the finished wall.
15 UNIT START UP
Turn on hot and cold water supplies, and check all
connections for leaks.
16 CLEANING THE AERATOR (Fig.N)
It is advisable to periodically clean the aerator, in order
to avoid build-up of dirt and limestone, which in time
could gradually limit the water flow. To clean the Aerator,
disassemble Aerator Housing by separating the Aerator
Head (1), Basket (2) and Washer (3). Once parts have been
cleaned, reassemble by reversing steps.
17 CARTRIDGE REMOVAL (Fig.P)
Turn off water supplies and relieve pressure
before working on your faucet! Remove Trim
Flange and Lever Handle (see steps 9 & 10). Close the
supply stops (1) clockwise with the use a screwdriver.
Loosen Set Screw (2) from Valve Body (3) and carefully
remove Temperature Knob (4). Remove Retainer Nut (5)
from Diverter Control (6) by unscrewing it counterclockwise.
Carefully remove Diverter Cartridge (7) by pulling it out.
Reassemble by reversing steps.
1
5
7
6
3
2
4
3
2
1
M
P
N
