Watlow Series SD User Manual
Page 5

Wa t l o w S e r i e s S D C a l i b r a t i o n
■
5
■
F a c t o r y a n d C a l i b r a t i o n
Display
Parameter Name
Description
Settings
Range
(Integer values for Modbus
in parentheses.)
Default
Modbus*
(less 40,001
offset)
Read/Write
Appears if:
[``U;9]
[ v.9]
Input Calibrate, 9.0 Volt
Calibrate the process voltage input to 9.0
Volt (see “Calibrating the Series SD”).
[``no]
[`yes]
[``no]
*NA
Always active.
[``A;4]
[ A.4]
Input Calibrate, 4.0 mA
Calibrate the process current input to 4.0
mA (see “Calibrating the Series SD”).
[``no]
[`yes]
[``no]
*NA
Always active.
[`A;16]
[ A.16]
Input Calibrate, 16.0 mA
Calibrate the process current input to
16.0 mA.
[``no]
[`yes]
[``no]
*NA
Always active.
[O1;1u]
[O1.1v]
Output 1 Calibrate, 1.0 Volt
The voltage process output transmits
1.000V.
[``no]
[`yes]
[``no]
*NA
Process output installed
for Output 1.
[O1;9u]
[O1.9v]
Output 1 Calibrate, 9.0 Volt
The voltage process output transmits
9.000V.
[``no]
[`yes]
[``no]
*NA
Process output installed
for Output 1.
[O1;4A]
[O1.4A]
Output 1 Calibrate, 4.0 mA
The current process output transmits
4.000 mA.
[``no]
[`yes]
[``no]
*NA
Process output installed
for Output 1.
[O1;16]
[O1.16]
Output 1 Calibrate, 16.0 mA
The current process output transmits
16.000 mA.
[``no]
[`yes]
[``no]
*NA
Process output installed
for Output 1.
[O3;1u]
[O3.1v]
Output 3 Calibrate, 1.0 Volt
The voltage process output transmits
1.000V.
[``no]
[`yes]
[``no]
*NA
Process output installed
for Output 3.
[O3;9u]
[O3.9v]
Output 3 Calibrate, 9.0 Volt
The voltage process output transmits
9.000V.
[``no]
[`yes]
[``no]
*NA
Process output installed
for Output 3.
[O3;4A]
[O3.4A]
Output 3 Calibrate, 4.0 mA
The current process output transmits
4.000 mA.
[``no]
[yes]
[``no]
*NA
Process output installed
for Output 3.
[O3;16]
[O3.16]
Output 3 Calibrate, 16.0 mA
The current process output transmits
16.000 mA.
[``no]
[`yes]
[``no]
*NA
Process output installed
for Output 3.
* The Series SD controller can be calibrated only with the front panel controls. These parameters
are not visible through serial communications.
