bad. The resistor will usually be black or dark brown if open. It should read a mini-
mal voltage of < 1V. If it reads line voltage R10 is bad. See Page 5 for ordering a
replacement transformer.
The QPAC Mother Board is Bad
Check the DC voltages at the J1 connector. Place the voltmeter common on pin 7
or 8. They should read as follows:
J1 Connector
Label
Without Card
With BF, AF or AL
Test Point
Card Installed
1
T STAT
Not Used
3 to 5V
2
-V
-11 to -14VDC
-15 to -22VDC
3
FWZ*
11 to 14VDC
11 to 14VDC*
4
+V
15 to 18VDC
15 to 18VDC
5
Q32, connected to Pin 1
Q01 or Q33
Not Used
Not Used
6
+5V
5V ±0.1V
5V ±0.1V
7
COM
8
COM (meter common)
9
KEY
10
COM
11
+LED
Not Used
Pulses possible
12
COM
*See scope pictures on Page 31.
Problem: Full or Partial Uncontrollable Heat
The SCR Switch is Shorted
Remove the control card and power up the QPAC. The output should be OFF. If
the unit is still full ON, remove power and disconnect the load wires and measure
across L1 and T1 with an ohmmeter. If resistance is low (5Ω or less), the SCR is
shorted and must be replaced. See Page 5 for ordering a replacement SCR.
A Heater is Partially Shorted or Shorted to Earth Ground
Disconnect the control card; the output should be OFF. If not, disconnect the
power and heater, and measure the heater resistance. It should match the heater
KW rating.
The Control Card has the Wrong Bias Adjustment
The bias adjustment is set too high and needs to be readjusted. See the Bias and
Gain Adjustment procedure with the appropriate control card on Page16.
The Control Card is Bad
First, try to re-seat the control card. Make sure there is a good connection between
the control card and the mother board. Power down the control and remove the
control card. Power up without the control card installed. If there is no heat, the
control card is bad. Replace the control card. See Page 5 for ordering.
An Excessive Input Signal from the Temperature Control
Check the input signal for proper calibration (i.e. 4-20mA at 4mA). The output
should be full OFF. At 20mA the output should be full ON.
The QPAC Mother Board is Bad
Refer to the mother board troubleshooting procedure on Page 28.
WATLOW QPAC Service Manual
19
Troubleshooting, Chapter 5
