AnaWin3 Quickstart Guide Installation
Doc.# 22852-10 Watlow Anafaze 7
Table 2.2 PPC-2010 Rotary Switch
Configuration
Switch positions A-D select the following settings:
• 19.2 kbaud (programmable)
• Even parity (fixed)
• 8 data bits (fixed)
• 1 stop bit (fixed)
Switch position H selects the following fixed settings:
• 19.2 kbaud
• Even parity
• 8 data bits
• 1 stop bit
Switch settings E-G are reserved.
Installing AnaWin3
To install AnaWin3, follow these steps:
1. Insert the disk labeled AnaWin Disk 1 in to the floppy
drive.
2. Click on then on the Windows system taskbar.
3. Type a:\setup or b:\setup.
4. The Setup program prompts you through the installation
process. Follow the instructions on the screen.
5. After installation you will be asked to reboot your PC.
6. After your PC has rebooted, on the Windows system task
bar, click
, then , then , then
.
7. The first time you run AnaWin3, you are prompted to en-
ter your serial number. You must enter the serial number
printed on AnaWin disk 1. Enter capital letters in the
first field. Do not enter the dash. Tab to or click on the
second field and enter the numbers.
Position Controller
Address
