Page 47

PS-3710A/PS-3711A Series Hardware Manual
2-20
Panel Cut Dimensions
Unit: mm[in.]
Installation Fasteners
Unit: mm[in.]
•
Please read "3.1.1 Installation (page 3-2)" before designing the Panel Cut.
383.5 [15.10 ]
+1
−0
28
2.5
[1
1.12
]
+1
−0
4-R3[0.12] or less
Panel thickness area
1.6[0.06] to 10.0[0.39]
+0.04
−0
+0.04
−0
16[0.63]
31[1.22]
M6
Φ
10[0.39
]
16.6[0.65]
1
1
[0
.4
3]
