INSTALLATION MANUAL 3
1010-0046A, REV 00
Read Me First!
Your new Maple Systems OIT comes from the factory configured with the default
communication settings: 9600 baud, no parity, 8 data bits, 1 stop bit, no
handshaking, no turn-around delay, 90 ° viewing angle, interactive mode, CR line
terminator, underline cursor, 1 space tab width, local echo enabled, local setup
enabled, local keyboard enabled, key click enabled, block echo enabled. You can
change these settings through the MAP450D’s local setup menus or by using the
STEPware-100 configuration software (sold separately). If you want to store
messages in the MAP450D, you must use STEPware-100.
Introduction
Thank you for purchasing a Maple Systems MAP450D. You have selected a
rugged, reliable, and powerful operator interface for your application. This booklet
describes the steps necessary to ensure trouble-free OIT system operation. Please
read this booklet carefully!!
Static Awareness
It is best NOT to remove the rear cover on the OIT except when accessing the
terminal block pins or panel mounting the OIT. When the rear cover is removed,
the circuitry inside is exposed to possible damage by electrostatic discharge during
handling. Minimize the possibility of electrostatic discharge by:
• Discharging personal static by grounding yourself prior to handling the OIT.
• Handling the OIT at static-free, grounded work stations.
• Connecting the chassis of the OIT to a clean ground.
• Placing the OIT into an anti-static bag during transport.
Unpacking the Unit
Carefully unpack the OIT. Please read any instructions or cautions that appear on
the shipping container. Check all material in the container against the enclosed
packing list. Maple Systems, Inc., will not accept responsibility for shortages
against the packing list unless notified within 30 days. The equipment and its
accessories were inspected and tested by Maple Systems before shipment; all of the
equipment should be in good working order. Examine the equipment carefully; if
any shipping damage is evident, notify the carrier immediately. You are
responsible for claim negotiations with the carrier. Save the shipping container and
packing material in case the equipment needs to be stored, returned to Maple
Systems, or transported for any reason.
CAUTION
To ensure that the OIT meets CE compliance, it is necessary to follow all
installation procedures described in this manual.
