SaltDogg 1400465SSH Self-Contained Hopper Spreader - Manual (Page 10)

10
ITEM PART NO. OTY. DESCRIPTION
1 3025428 1 UPPER CHUTE WELDMENT
2 3025432 1 LOWER CHUTE WELDMENT
3 – 8 SCREW, HHC-3/8- 1 6 X 3/4 SST
4 – 9 NUT, NYLOCK 3/8- 1 6X7/16 SST
5 3025430 1 SHIELD, CHUTE
6 – 3 BOLT, 3/8-16 X 1 CARRIAGE SHORT NECK
7 3025431 1 BAFFLE
8 – 2 SCREW, HHC 3/8- 16 X 1 304 SST
9 3024581 1 PIN, CHUTE ADJUSTMENT
10 HP9 2 PIN, HAIR COTTER, .09 ZINC
ITEM PART NO. OTY. DESCRIPTION
11 1410241 1 WIPER BELT, HOPPER
12 – 3 WASHER, FLAT 1 /4 SAE SS
13 – 3 SCREW, CAP 1 /4-20 X 3/4 SST
14 – 3 NUT, NYLON INSERT 1/4-20 SST
15 9240131 1 DECAL #1 , DANGER STAY CLEAR
16 CM004P 1 MOTOR, HYD 4 BOLT
17 – 4 WASHER, LOCK RHS-3/8 SST
18 30086 1 1 1 DISC, SPINNER ASSEMBLY
19 – 1 WASHER, 5/16 SAE SST
20 – 1 SCREW HH CAP 1 /4-20 X 3.0 SST
Bill of Materials
Chute Assembly - Hydraulic Model
