Ramsey Winch REP-6000/8000/9000 User Manual
Ramsey Winch For the car
Congratulations
You have purchased the finest winch avail-
able in its service class. The REP 6000, REP
8000 and REP 9000 feature a highly efficient
3 stage planetary gear set. The REP 6000
and REP 8000 transmit torque from a perma-
nent magnet D.C. motor, while the REP 9000
utilizes a series wound D.C. motor. A safe
positive clutch allows free spooling for quick
cable deployment. An automatic load holding
brake is designed to hold the full rated
capacity of the winch. It was designed and
manufactured to provide you with the utmost
in utility. As with any device that combines
power and movement in its use, there are
dangers if improperly used. At the same
time, there are easier and faster ways for
getting the job done if certain precautions are
taken first. Please read this manual carefully.
It contains useful ideas in obtaining the most
efficient operation from your Ramsey Winch
and safety procedures you need to know
before beginning use. When you follow our
guidelines for operation, your Ramsey Winch
will give you many years of satisfying serv-
ice. Thank you for choosing Ramsey. You will
be glad you have one working for you.
Please Note: Ramsey REP6000, REP8000 and REP9000
Series winches are designed for front mount vehicle use.
The winches are not designed for and should not be used
in industrial applications (car haulers/carriers, wreckers,
hoisting, etc.), and Ramsey does not warrant them to be
suitable for such use. Ramsey makes a separate, com-
plete line of winches for industrial/commercial use.
Please contact the factory for further information.
Ramsey Winch Company
OWNER’S MANUAL
Front Mount Electric Winches
Contents
Safety Precautions ..............................2
Tips for Safe Operation........................2
Techniques of Operation......................3
Installation ......................................4-5
Electrical Connections & Operations ....8
Maintenance ......................................8
Operating Instructions ........................9
Trouble Shooting Guide ....................10
Winch Parts List ..........................11-15
Warranty..............................Back Cover
CAUTION: Read and understand this manual before installation and operation of winch. See Safety Precautions.
Model REP 6000
Model REP 8000
Model REP 9000
Ramsey performance data is compiled from actual winch testing
LINE SPEED
(FPM)
CURRENT
(AMPS)
(lbs)
(kg)
12V
12V
LAYER
FT.*
M*
0
0
25
70
1
20
6
1,000
450
21
155
2
50
15
3,000
1,350
16
240
3
80
24
5,000
2,260
10
370
4
100
30
6,000
2,710
8
440
REP 6000
PERFORMANCE FIRST LAYER OF CABLE
LINE PULL
(1/4" (6 MM) DIA. CABLE)
CUMULATIVE BY LAYER
CABLE DRUM CAPACITY
* DEPENDS ON CABLE BEING
UNIFORMLY WOUND ONTO DRUM.
LINE SPEED
(FPM)
CURRENT
(AMPS)
(lbs)
(kg)
12V
12V
LAYER
FT.*
M*
0
0
18
60
1
15
4
2,000
900
15
150
2
40
12
4,000
1,810
12
220
3
70
21
6,000
2,710
9
310
4
95
28
8,000
3,620
6
420
* DEPENDS ON CABLE BEING
UNIFORMLY WOUND ONTO DRUM.
REP 8000
PERFORMANCE FIRST LAYER OF CABLE
CABLE DRUM CAPACITY
LINE PULL
(5/16" (8 MM) DIA. CABLE)
CUMULATIVE BY LAYER
(lbs)
(kg)
12V
24V
12V
24V
LAYER
FT.*
M*
0
0
33
25
97
35
1
15
4
2,000
900
17
15
180
75
2
40
12
4,000
1,810
13
11
260
110
3
70
21
6,000
2,710
11
9
335
140
4
95
28
9,000
4,070
8
7
420
175
LINE SPEED
(FPM)
CURRENT
(AMPS)
LINE PULL
(5/16" (8 MM) DIA. CABLE)
CUMULATIVE BY LAYER
REP 9000
PERFORMANCE FIRST LAYER OF CABLE
CABLE DRUM CAPACITY
* DEPENDS ON CABLE BEING
UNIFORMLY WOUND ONTO DRUM.
