Ramsey Winch ATV-3000 - Manual (Page 11)

11
Winch Parts List ATV3000 (Wireless Remote)
Electrical Schematic (Wireless Remote)
ITEM
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
PART
NO.
251214
251189
251191
251192
251193
251194
251236
251195
251196
251197
282058
251190
251234
251235
251198
257522
DESCRIPTION
MOTOR KIT
MOTOR END GEAR SET
CLUTCH KIT
CABLE DRUM KIT
CABLE & HOOK KIT
CLUTCH END GEAR KIT
ROLLER FAIRLEAD (ON CERTAIN MODELS)
BUSHING KIT
TIE BAR KIT
ELECTRICAL WIRING KIT
WIRELESS RECEIVER & TRANSMITTER KIT
WIRELESS TRANSMITTER
SOLENOID KIT
TOGGLE SWITCH
ANTENNA KIT
HARDWARE KIT*
Programing instructions: Press and hold membrane below,
press ON/OFF button on transmitter for 3 seconds ,
press OUT button for 3 seconds or until winch activation .
WWW.RAMSEY.COM
(918)438-2760 FAX(918)438-6688 Tulsa . Oklahoma, USA .
.
PUSH
BLACK WIRE
TO GROUND
WIRING
HARNESS
YELLOW WIRE
SOLENOID ASS’Y.
BLACK W/
YELLOW STRIPE
MOTOR LEAD
RED
BATTERY LEAD
BLACK
BATTERY LEAD
#1
MOTOR
BATTERY
#2
YELLOW WIRE
YELLOW
WIRE
GREEN WIRE
GREEN WIRE
BLACK MOTOR
LEAD
GREEN WIRE
WIRELESS
SIGNAL
RED WIRE W/
WHITE STRIPE TO
ACCESSORY WIRE
ON VEHICLE IGNI-
TION
RED WIRE
ANTENNA
RECEIVER
TOGGLE SWITCH
COAX CABLE
FEMALE SPADE
CONNECTOR
MALE SPADE
CONNECTOR
NOTE:
TORQUE SOLENOID
TERMINAL NUTS TO
35-40 IN-LBS.
ON
/O FF
OU
T
IN
TRANSMITTER
WIRE SPLICE
