Page 19
14
If you do not have a DHCP server, get an IP
address and subnet mask from your network
administrator, type it into the area provided, and
click on Next.
5
Click on Launch Browser.
Your browser points to the ATTO ExpressNAV
splash screen. If you use Internet Explorer as a
browser, you may continue on to the optional
below. If not, continue on
to
Internet Explorer setup
1
Open your browser
2
Select
Internet Options.
3
In the
Internet Options screen, select the
Security tab.
4
Click on the
Trusted Sites icon.
5
Click on the
Sites button.
6
In the text box
Add this Web site to the zone,
add the IP address of the appliance. You may
use wild cards.
7
Click on Add.
8
Uncheck the
Require server verification
check box.
9
Click
OK.
10 At the bottom of the
Internet Options box, click
on OK and close the box.
Begin initial configuration
1
The ExpressNAV interface welcome screen
appears. Click on Enter Here.
2
Type in the user name and password.
Note
The default values are user name root and
password Password. The user name is case
insensitive and the password is case
sensitive.It is best practice to change the
default user name and password. Refer to
3
The ExpressNAV FibreBridge status page
appears. Continue to
Exhibit 2.0-1 Brackets to install the FibreBridge 2390R/D or 2400R/D into a rack.
Exhibit 2.0-2 Typical FibreBridge connectors, LEDs and power receptacle
Ready/Fault LED
Ethernet port
Fibre Channel ports
SCSI ports
SCSI activity LEDs
FC activity & link LEDs
Serial port
Power receptacle
air vents
.
