A-1
INSTALLATION SAE-300 ® HE
TECHNICAL SPECIFICATIONS - SAE-300 ® HE
Make/Model Description Speed (RPM) Displacement Starting Dry
System Capacities
3 Cylinder 91.47 cu. in 12VDC battery Fuel: 16 gal.
24.7 HP(18.4kW) (1.5 ltrs) (Group 24, 650 60.6 L.
PERKINS TURBO High Idle 1800 cold crank amps)
403F-15T CHARGED Low Idle 1440 Bore x Stroke 2.0 KW Starter Oil: 6.34 Qtrs.
EPA DIESEL Full Load 1800 6.0 L.
Tier 4 ENGINE 3.3” x 3.5”
Compliant (84mm x 90mm) Coolant: 7.76 Qts.
7.3 L.
65 A. Alternator
w/ built in reg.
INPUT - DIESEL ENGINE
RATED OUTPUT @ 104°F(40°C) - WELDER
MODEL HEIGHT WIDTH DEPTH WEIGHT
K3202-1 45.5 in. (2) 24.3 in. 62.8 in. 1419 lbs.
CSA Without (1156 mm) (616 mm) (1594 mm ) (644 kg.)
Wire Feed Module
RATED OUTPUT @ 104°F(40°C) - GENERATOR
DESCRIPTION RATED DC OUTPUT * Duty
VOLTS @ RATED AMPS CYCLE
300 Amp DC Welder 30V @ 250A 100%
All Copper Windings 32V @ 300A 60%
Pure DC Power Generator 90V DC Max. OCV @ 1800RPM
Auxiliary Power (1)
3,000 Watts Continuous, 60 Hz AC
26 Amps @ 120V
13 Amps @ 240V
PHYSICAL DIMENSIONS (2)
*
Based on a 10 min. period.
(1) Output rating in watts is equivalent to volt-amperes at unity power factor. Output voltage is within ± 10% at all loads up to
rated capacity. When welding, available auxiliary power will be reduced.
(2) Height to top of exhaust elbow.
