29A Thread Forming Screw (Not Shown) S9225-26 4 X
29B Lock Washer (Not Shown) T9860-3 4 X
30A Receptacle Cover M16996 2 X
30B Receptacle Gasket S21088 2 X
31 3 Year Warranty Decal (Not Shown) S22127-3 1 X
32 Electronic Governor Controller (Not Shown) * 1 X
Plain Washer S9262-27 4 X
Lock Washer T9695-1 2 X
#10-24 HN CF000010 2 X
Spacer S10918-69 2 X
#10-24 x 1.75 RHS CF000127 2 X
33 Current Sensor P.C. Board (Not Shown) S25590-2 1 X
34A Lower Control Nameplate L16333 1 X
34B Fastener Button T14659-2 2 X
35 Right Side Case Front Guard (Not Shown) M24952 1 X
36 Left Side Case Front Guard (Not Shown) M24953 1 X
37 Harness (Not Shown) G7519 1 X
38 Terminal Block (Not Shown) S29970 1 X
510 Ohm Resistor S10400-5100 1 X
1.5K Ohm Resistor S10404-1501 1 X
Oct-13
SAE-300 ® HE
Use only the parts marked “x” in the column under the
heading number called for in the model index page. # Indicates a change this printing.
P-736-D.2
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-736-D.2
Note: When ordering new printed circuit boards indicate the dash number [ ] of the “Old” board
that is to be replaced. This will aid Lincoln in supplying the correct and latest board along
with any necessary jumpers or adapters. The dash number brackets [ ] have purposely
been left blank so as to eliminate errors, confusion and updates.
* Contact Engine Manufacturer
