Lincoln Electric IM10155 SAE-300 HE - Manual (Page 47)

Perkins Diesel Engine Asbly (L16311), Includes: NSS 1 X
1 Engine (Perkins 403F-T Diesel) (M24738) NSS 1 X
2 Fuel Filter (Supplied w/Engine) * 1 X
M10-1.50x35 HHS w/Lock Washer (Supplied w/Engine) * 2 X
3 Air Filter Mounting Bracket L16328 1 X
M8-1.25x16HHS w/Lock Washer (Supplied w/Engine) * 2 X
Air Filter Vertical Brace S29527 1 X
Thread Forming Screw S9225-26 1 X
M8-1.25x20mm SHCS T14731-3 1 X
Lock Washer E106A-3 1 X
Air Filter Mounting Band M20359 1 X
5/16-18x1.25 HHCS CF000028 2 X
5/16-18 HN CF000029 2 X
Lock Washer E106A-3 2 X
Plain Washer S9262-121 4 X
Hose M24773 1 X
Hose Clamp S10888-33 2 X
4 Starter (Supplied w/Engine) * 1 X
3/8-16x1.00 HHCS CF000019 1 X
Lock Washer E106A-4 1 X
M6 LOCK WASHER S17400-3 1 X
M6 X 1.0 HN T14815-3 1 X
5 Muffler L16324 1 X
Exhaust Gasket (Supplied w/Engine) * 1 X
M8-1.25x25HHS w/Lock Washer (Supplied w/Engine) * 4 X
6 Flex Hose (Oil Drain) T10642-218 1 X
Clamp S10888-27 1 X
7 Engine Mounting Foot S29473 2 X
M14-1.5x25 HHS T14731-48 8 X
Lock Washer S17400-5 8 X
9 Bottom Fan Guard L16329 1 X
10 Hose, Breather T10642-354 1 X
Fitting S26600 1 X
Hose Clamp S10888-27 2 X
11 Bracket - Speed Sensor S29649 1 X
Speed Sensor S29889 1 X
12 Flywheel Lock Stud S29603 4 X
14 Upper Radiator Hose L16326 1 X
Hose Clamp S10888-8 1 X
Hose Clamp S10888-44 1 X
15 Lower Radiator Hose L16327 1 X
Hose Clamp S10888-8 1 X
Hose Clamp S10888-44 1 X
Oct-13
SAE-300 ® HE
Use only the parts marked “x” in the column under the
heading number called for in the model index page. # Indicates a change this printing.
P-736-E.1
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-736-E.1
NSS - Not Sold Separately
* Contact Engine Manufacturer
