B-1 OPERATION
LTA 2.0-CW™
B-1
GENERAL DESCRIPTION
The LTA 2.0-CW™ is a wall-mounted telescopic
extraction arm with a rotatable hood. Located in the
hood is a throttle valve that can be fully opened, par-
tially opened or completely closed to control airflow.
The arm features a focus extraction spoiler which
directs the air into the hood. The extraction arm is
based on a telescopic tube, allowing it to be extended
to give a 8.2 ft (2.5 m) working radius and com-
pressed to 5 ft (1.5 m). The arm is fitted with a spring
balance which enables it to be moved from a vertical
to a horizontal position in one easy movement. If
mounted on a column, the arm can be turned 300°
due to the rotating hinge. The LTA 2.0-CW™ is often
used in welding booths.
MANUAL OPERATION
The extracted welding fume enters the extraction arm
via the rotatable hood. The arm discharges the pollut-
ed air to a filter unit or directly to the atmosphere. The
hood of the arm is fitted with a throttle valve, which
can be controlled using the rotary knob(s). The throttle
valve is mostly used when several extraction arms are
integrated in a line installation; in such configurations
closing the throttle valve prevents the loss of costly
heated air.
NOTE: If an automatic damper system is part of the
assembly, keep the manual damper open at
all times.
ELECTRIC SHOCK CAN KILL
The manufacturer does not accept any liability for
damage to the product or personal injury caused
by ignoring the safety instructions in this manual,
or by negligence during installation, use, mainte-
nance, and repair of the product mentioned on
the cover of this document and any correspond-
ing accessories. Specific working conditions or
used accessories may require additional safety
instructions. Immediately contact your supplier if
you detect a potential danger when using the
product.
The user of the product is always fully responsi-
ble for observing the local safety instructions and
regulations. Observe all applicable safety instruc-
tions and regulations.
WARNING
USER MANUAL
• Everyone working on or with the product, must be
familiar with the contents of this manual and must
strictly observe the instructions therein. The man-
agement should instruct the personnel in accor-
dance with the manual and observe all instructions
and directions given.
• Never change the order of the steps to perform.
• Always keep the manual with the product.
USERS
• The use of this product is exclusively reserved to
well authorized, trained and qualified users.
Temporary personnel and personnel in training can
only use the product under supervision and respon-
sibility of skilled engineers.
• Use common sense. Stay alert and keep your atten-
tion on your work. Do not use the product when you
are under the influence of drugs, alcohol or medi-
cine.
• The product is not to be used by children or persons
with reduced physical, sensory or mental capabili-
ties, or lack of experience and knowledge.
INTENDED USE
This product has been designed exclusively for
extracting gases and particles which are released
during the most common welding processes. Using
this product for other purposes is considered contrary
to its intended use. The manufacturer accepts no lia-
bility for any damage or injury resulting from such
use. The product has been built in accordance with
state-of-the art standards and recognized safety regu-
lations. Only use this product when in technically per-
fect condition in accordance with its intended use and
the instructions explained in the user manual.
