Pipe Thawing with an arc welder can cause fire,
explosion, damage to electric wiring or to the arc
welder if done improperly. The use of an arc
welder for pipe thawing is not approved by the
CSA, nor is it recommended or supported by
Lincoln Electric.
------------------------------------------------------------------------
K3088-1 Air Filter Kit - Reduces oil, water and partic-
ulates in supply air.
TIG OPTIONS
K870 Foot Amptrol ® - Varies current while welding for
making critical TIG welds and crater filling. Depress
pedal to increase current. Depressing pedal fully
achieves maximum set current. Fully raising the pedal
finishes the weld and starts the afterflow cycle on sys-
tems so equipped. Includes 25 ft. (7.6m) control cable.
K963-3 Hand Amptrol ® - Varies current for making
critical TIG welds. Fastens to the torch for convenient
thumb control. Comes with a 25 ft. (7.6m) cable. (for
larger handle 18 or 26 series torches)
C-1 ACCESSORIES C-1
AIR VANTAGE ® 650 CUMMINS
OPTIONAL FIELD INSTALLED
ACCESSORIES
K802N POWER PLUG KIT - Provides four 120V
plugs rated at 20 amps each and one dual voltage,
full KVA plug rated at 120/240V, 50 amps. 120V plug
may not be compatible with NEMA common house-
hold receptacles.
K802-R POWER PLUG KIT - Provides four 120V
plugs rated 15 amps each and one dual voltage, full
KVA plug rated at 120/240V, 50 amps, 120V plug is
compatible with NEMA common household recepta-
cles.
K857 25 ft. (7.5 m) or K857-1 100 ft. (30.4 m) REMOTE CON-
TROL - Portable control provides same dial range as the output
control on the welder from a location up to the specified length
from the welder. Has convenient plug for easy connection to the
welder. The AIR VANTAGE
® 650 CUMMINSis equipped with a
6-pin connector for connecting the remote control.
K704 ACCESSORY SET - Includes 35 feet (10 m) of
electrode cable and 30 feet (9 m) of work cable, head-
shield, filter plate, work clamp and electrode holder.
Cable is rated at 500 amps, 60% duty cycle.
K2641-2 FOUR WHEELED STEERABLE YARD
TRAILER
For in plant and yard towing. Comes standard with a
Duo-Hitch™, a 2” Ball and Lunette Eye combination
Hitch.
K2637-2 TRAILER - Two-wheeled trailer with optional fender
and light package. For highway use, consult applicable feder-
al, state, and local laws regarding possible additional require-
ments. Comes standard with a Duo-Hitch™, a 2” Ball
and Lunette Eye combination hitch. A fender & a light
package. Order:
K2637-2 Trailer
K2639-1 Fender & Light Kit
K2640-1 Cable Storage Rack
K887-1 ETHER START KIT - Provides maximum cold weath-
er starting assistance for frequent starting below 10°(-12°C).
Required Ether tank is not provided with kit.
WARNING
