If desired, the K930-2 TIG Module can be used with
the AIR VANTAGE
® 650 CUMMINS. The settings are
for reference.
AIR VANTAGE ® 650 CUMMINS settings when using
the K930-2 TIG Module with an Amptrol or Arc Start
Switch:
• Set the MODE Switch to the TOUCH START TIG
setting.
• Set the "IDLER" Switch to the "AUTO" position.
• Set the "WELDING TERMINALS" switch to the
"REMOTELY CONTROLLED" position.
This will keep the "Solid State" contactor open and
provide a "cold" electrode until the Amptrol or Arc
Start Switch is pressed.
When using the TIG Module, the OUTPUT CONTROL
on the AIR VANTAGE
® 650 CUMMINS is used to set
the maximum range of the CURRENT CONTROL on
the TIG Module or an Amptrol if connected to the TIG
Module.
NOTE: The TIG process is to receive a low voltage
welding process. There is no difference in
operation with the VRD “On” or “Off” for this
mode. For indicator light operation, see Table
B.1.
TIG WELDING
The TOUCH START TIG setting of the MODE switch
is for DC TIG (Tungsten Inert Gas) welding. To initiate
a weld, the OUTPUT CONTROL dial is first set to the
desired current and the tungsten is touched to the
work. During the time the tungsten is touching the
work there is very little voltage or current and, in gen-
eral, no tungsten contamination. Then, the tungsten is
gently lifted off the work in a rocking motion, which
establishes the arc.
When in the TOUCH START TIG mode and when a
Amptrol is connected to the 6-Pin connector the OUT-
PUT CONTROL dial is used to set the maximum cur-
rent range of the current control of the Amptrol.
The ARC CONTROL is not active in the TIG mode. To
STOP a weld, simply pull the TIG torch away from the
work.
When the arc voltage reaches approximately 30 Volts
the arc will go out and the machine will reset the cur-
rent to the Touch Start level.
To reinitiate the arc, retouch the tungsten to the work
and lift. Alternatively, the weld can be stopped by
releasing the Amptrol or arc start switch.
The AIR VANTAGE ® 650 CUMMINS an be used in a
wide variety of DC TIG welding applications. In gener-
al the ʻTouch Startʼ feature allows contamination free
starting without the use of a Hi-frequency unit.
B-9 OPERATION B-9
AIR VANTAGE ® 650 CUMMINS
TYPICAL CURRENT RANGES (1) FOR TUNGSTEN ELECTRODES (2)
Tungsten Electrode DCEN (-) DCEP (+) Approximate Argon Gas Flow TIG TORCH
Diameter in. (mm) Flow Rate C.F.H. ( l /min.) Nozzle Size (4), (5)
1%, 2% Thoriated 1%, 2% Thoriated Aluminum Stainless Steel
Tungsten Tungsten
.010 (.25) 2-15 (3) 3-8 (2-4) 3-8 (2-4) #4, #5, #6
0.020 (.50) 5-20 (3) 5-10 (3-5) 5-10 (3-5)
0.040 (1.0) 15-80 (3) 5-10 (3-5) 5-10 (3-5)
1/16 (1.6) 70-150 10-20 5-10 (3-5) 9-13 (4-6) #5, #6
3/32 (2.4) 150-250 15-30 13-17 (6-8) 11-15 (5-7) #6, #7, #8
1/8 (3.2) 250-400 25-40 15-23 (7-11) 11-15 (5-7)
5/32 (4.0) 400-500 40-55 21-25 (10-12) 13-17 (6-8) #8, #10
3/16 (4.8) 500-750 55-80 23-27 (11-13) 18-22 (8-10)
1/4 (6.4) 750-1000 80-125 28-32 (13-15) 23-27 (11-13)
(1) When used with argon gas. The current ranges shown must be reduced when using argon/helium or pure helium shielding gases.
(2) Tungsten electrodes are classified as follows by the American Welding Society (AWS):
Pure EWP
1% Thoriated EWTh-1
2% Thoriated EWTh-2
Though not yet recognized by the AWS, Ceriated Tungsten is now widely accepted as a substitute for 2% Thoriated Tungsten in AC and DC applications.
(3) DCEP is not commonly used in these sizes.
(4) TIG torch nozzle "sizes" are in multiples of 1/16ths of an inch:
# 4 = 1/4 in. (6 mm)
# 5 = 5/16 in. (8 mm)
# 6 = 3/8 in. (10 mm)
# 7 = 7/16 in. (11 mm)
# 8 = 1/2 in. (12.5 mm)
#10 = 5/8 in. (16 mm)
(5) TIG torch nozzles are typically made from alumina ceramic. Special applications may require lava nozzles, which are less prone to breakage, but cannot withstand high temperatures
and high duty cycles.
TABLE B.3
