LKM Series Console Drawer
2.3.2 24V/48V DC Input Power Adapters
Table 2-5 lists the 24V/48V DC power adapter specifications.
24V DC Input 48V DC Input
MFR./Model Skynet / ACE-023C Skynet / ACE-023T
EMI Standards FCC Docket 20780 curve”B” EN 55022”B”
EMS Standards
IEC-61000-4-2: 4KV contact; 8KV air discharge criterion B
IEC-61000-4-3: 3V/M with 80% AM criterion A
IEC-61000-4-4: 2KV criterion B
Input Voltage Range 18VDC - 32VDC 36VDC - 72VDC
Input Current 2.5A max. at 24VDC
Inrush Current 15A max. at 24VDC (25º Cold Start)
Output Load Range
+5V output, 4A rated load
+12V output, 0.75A rated load
Output Power >30W at 24VDC
Ripple and Noise >1.2% of output voltage peak to peak
Line Regulation >±1% at rated load
Load Regulation 5V >±5% and 12V >±4% at 60% rated load, 24VDC input
Short Circuit Protection Continuous
Over-voltage Protection Yes
Humidity 20 ~ 95%, non-condensing
Operation Temperature 0 ~ 50°C
Storage Temperature -40 ~ 85°C
Table 2-5: 24V/48V DC Power Adapter Specifications
