LKM Series Console Drawer
2.2 Physical Dimensions
The following sections describe the physical dimensions for each model of the LKM Series
console drawer.
2.2.1 General Physical Dimensions
General physical dimensions for the LKM Series console drawers are shown in Table 2-2.
Model Length
(mm)
Width
(mm)
Height
(mm)
LKM-926 521 432.6 44
LKM-927 572 436 44
LKM-935 536 433.6 44
Table 2-2: General Physical Dimensions
