PPC-37xx-N270 Panel PC
Page 131
A.2.1 PPC-3708A-N270 Flat Panel Specifications
The PPC-3708A-N270 comes with an 8.4” TFT LCD monitor at the front of the flat panel
PC. The specifications for the LCD monitor are shown in the table below.
SPECIFICATION PPC-3708A-N270
Model Toshiba-LTA084C270F
Size 8.4”
Resolution
SVGA (800 x 600)
Active Area (mm)
170.4 x 127.8
Pixel Pitch (mm)
0.213 x 0.213
Mode TN
Number of Colors 256 K
View Angel (H/V) 120/100
Brightness (cd/m
2
) 400
Contrast Ratio 450:1
Response Time (ms) (at 25°C) 8 (t
ON
), 17 (t
OFF
)
Interface 1ch LVDS
Supply Voltage (V) 3.3
Backlight 2 CCFL
Outline Dimensions (mm) 199.5 x 149.5 x 12.0
Weight (g) 460
A.2.2 PPC-3710A-N270 Flat Panel Specifications
The PPC-3710A-N270 comes with a 10.4” TFT LCD monitor at the front of the flat panel
PC. The specifications for the LCD monitor are shown in the table below.
SPECIFICATION PPC-3710A-N270
Model
Toshiba-LTA104D182F-02
Size 10.4”
