TANK-820 Em b e d d e d S ys te m
P a g e 4
S p e c ific a tio n s
Eth e rn e t Co n tro lle r Dual Realtek RTL8111E PCIe GbE controllers with ASF 2.0 support
I/O a n d In d ic a to rs
Eth e rn e t 2 x RJ-45 GbE ports
RS -232 4 x RS-232 serial ports (DB-9)
2 x RS-232 serial ports (DB-9 with isolation)
RS -422/RS -485 2 x RS-422/485 serial ports (RJ-45)
US B In te rfa c e s 4 x USB 2.0 ports on front side
2 x USB 3.0 ports on rear side
Dis p la y 1 x VGA port (2048 x 1536 @ 75Hz)
1 x DVI-I port (1920 x 1080 @ 60Hz)
Au d io Co n n e c to r 1 x Line-out port
1 x Mic-in port
Dig ita l I/O 1 x DB-9 port on rear side
In te rio r Exp a n s io n s Either one PCIe x8 (via PCIe x16 slot) and two PCI
or one PCIe x1 (via PCIe x4 slot), one PCIe x8 (via PCIe x16 slot)
and one PCI
LED In d ic a to rs AT power mode LED
ATX power mode LED
CPU temperature alert LED
HDD LED
Power 1 LED
Power 2 LED
S to ra g e
S ATA 2.5’’ SATA HDD bay
Co m p a c tFla s h ® One CompactFlash® Type II socket
P o we r
P o we r S u p p ly Redundant dual DC input
Terminal Block: 9 ~ 24V
DC Jack: 9 ~ 24V
