2 mounting option 2, Figure 4–19: mounting screws – IEI Integration uIBX-200 v1.10 User Manual
Page 40
UIBX-200-R11/Z510P Embedded System
Page 30
Step 4:
Attach the monitor and UIBX-200-R11/Z510P to a stand using the VESA
mounting holes on the UIBX-200-R11/Z510P.
Step 0:
Figure 4–19: Mounting Screws
Three common methods of mounting the UIBX-200-R11/Z510P are listed in the
subsections below.
4.6.2 Mounting Option 2
To install the UIBX-200-R11/Z510P on the VESA mounting slot, between the monitor
stand and the monitor, follow the instructions below.
