NOVA-945GSE 5.25” SBC
Page 74
NOTE:
IEI has a wide range of backplanes available. Please contact your
NOVA-945GSE vendor, reseller or an IEI sales representative at
2
[email protected] or visit the IEI website (
2
http://www.ieiworld.com.tw)
to find out more about the available chassis.
4.6.2 Motherboard Installation
To install the NOVA-945GSE motherboard into the chassis please refer to the reference
material that came with the chassis.
4.7 Internal Peripheral Device Connections
4.7.1 Audio Kit Installation
The Audio Kit that came with the NOVA-945GSE connects to the 10-pin audio connector
on the NOVA-945GSE. The audio kit consists of three audio jacks. One audio jack, Mic In,
connects to a microphone. The remaining two audio jacks, Line-In and Line-Out, connect
to two speakers. To install the audio kit, please refer to the steps below:
Step 1: Locate the audio connector. The location of the 10-pin audio connector is
shown in Chapter 3.
Step 2: Align pin 1. Align pin 1 on the on-board connector with pin 1 on the audio kit
connector. Pin 1 on the audio kit connector is indicated with a white dot. See
Figure 4-10.
