NOVA-945GSE 5.25” SBC
Page 20
Specification NOVA-945GSE
Display port One VGA
One TV-out connector support HDTV by component interface
One 18-bit dual channel LVDS connector
One 18/24-bit dual channel LVDS connector
(NOVA-945GSELVDS2-N270 only)
Ethernet Two RJ-45 GbE ports
Keyboard/Mouse One 6-pin header for keyboard and mouse
Parallel Port One IEEE 1284 parallel port (26-pin header) supporting
normal, EPP and ECP modes
Serial Ports Five via internal pin headers
Three RS-232
One RS-232/422/485
USB 2.0/1.1 ports Six USB 2.0 devices supported by on-board pin-headers
Infrared
One infrared connector through the ITE super I/O. Supports:
Serial Infrared (SIR)
Amplitude Shift Keyed IR (ASKIR)
TPM One 20-pin header supports TPM function
Digital I/O
One 8-bit digital input/output connector; 4-bit input/4-bit output
through the ITE IT8718F super I/O
Storage
Serial ATA Two independent serial ATA (SATA) channels with 1.5 Gb/s
data transfer rates
IDE One 44-pin IDE connector connects to two Ultra
ATA33/66/100 devices
