NOVA-945GSE 5.25” SBC

Page 123

BIOS SETUP UTILITY

Main

Advanced

PCIPNP

Boot

Security

Chipset

Power

Exit

Video Function Configuration
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
DVMT Mode Select

[DVMT Mode]

DVMT/Fixed Memory

[128 MB]

Boot Display Device

[CRT]

LVDS2 Panel Type

[1024x768 24b]

LVDS2 Current Jumper Setting

[1024x768 18b]

Select

Screen

↑ ↓ Select

Item

Enter Go to SubScreen
F1 General

Help

F10

Save and Exit

ESC Exit

BIOS Menu 19:Northbridge Chipset Configuration

DVMT Mode Select [DVMT Mode]

Use the DVMT Mode Select option to select the Intel Dynamic Video Memory Technology

(DVMT) operating mode.

Fixed Mode

A fixed portion of graphics memory is reserved as

graphics memory.

DVMT Mode

EFAULT

Graphics memory is dynamically allocated

according to the system and graphics needs.

Combo Mode

A fixed portion of graphics memory is reserved as

graphics memory. If more memory is needed,

graphics memory is dynamically allocated

according to the system and graphics needs.

DVMT/FIXED Memory [128MB]

Use the DVMT/FIXED Memory option to specify the maximum amount of memory that

can be allocated as graphics memory. This option can only be configured for if DVMT

Mode or Fixed Mode is selected in the DVMT Mode Select option. If Combo Mode is
