PIN DESCRIPTION PIN DESCRIPTION
5 USBPWR1/2 6 USB20_C_N1
7 USB20_C_P1 8 GND
Table 3-28: LAN1_USB Port Pinouts
PIN DESCRIPTION PIN DESCRIPTION
1 USB_3P0_VCC1 2 USB2P0_DM1_L
3 USB2P0_DP1_L 4 GND
5 USB3P0_RXDN1 6 USB3P0_RXDP1
7 GND 8 USB3P0_TXDN1_C
9 USB3P0_TXDP1_C 10 USB_3P0_VCC2
11 USB2P0_DM2_L 12 USB2P0_DP2_L
13 GND 14 USB3P0_RXDN2
15 USB3P0_RXDP2 16 GND
17 USB3P0_TXDN2_C 18 USB3P0_TXDP2_C
Table 3-29: LAN2_USB Port Pinouts
3.3.4 HDMI Port Connector
CN Label: HDMI
CN Type: HDMI connector
CN Location: See Figure 3-24
CN Pinouts: See Table 3-30
The HDMI port connects to an HDMI device.
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 HDMI_TMDS_C_DATA2 13 NC
2 GND 14 NC
3 HDMI_TMDS_C_DATA2# 15 HDMI_DDC_SCLK
4 HDMI_TMDS_C_DATA1 16 HDMI_DDC_SDATA
5 GND 17 GND
6 HDMI_TMDS_C_DATA1# 18 +5V
