5.3.10 Serial Port Console Redirection
The Serial Port Console Redirection menu (BIOS Menu 16) allows the console
redirection options to be configured. Console redirection allows users to maintain a
system remotely by re-directing keyboard input and text output through the serial port.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
COM1
Console Redirection [Disabled]
> Console Redirection Settings
COM2
Console Redirection [Disabled]
> Console Redirection Settings
COM3
Console Redirection [Disabled]
> Console Redirection Settings
COM4
Console Redirection [Disabled]
> Console Redirection Settings
COM5
Console Redirection [Disabled]
> Console Redirection Settings
COM6
Console Redirection [Disabled]
> Console Redirection Settings
COM7
Console Redirection [Disabled]
> Console Redirection Settings
COM8
Console Redirection [Disabled]
> Console Redirection Settings
COM9
Console Redirection [Disabled]
> Console Redirection Settings
COM10
Console Redirection [Disabled]
> Console Redirection Settings
iAMT SOL
> Console Redirection Settings
Console Redirection
Enable or Disable
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 16: Serial Port Console Redirection
Î Console Redirection [Enabled]
Use Console Redirection option to enable or disable the console redirection function.
